McGill AirClean LLC products

McGill AirClean has been manufacturing fabric filter (baghouse) systems since 1991. Recently, we have modified our fabric filter system design to include the use of high temperature (750°F) ceramic catalytic filters. The catalytic filters remove both particulate and NOx (with ammonia injection), and provide a secondary reaction site for acid gas reduction (SOx, HCl, HF, and B2O3). We currently have 3 systems operating, and 3 under construction.

We have developed a wet ESP system for applications involving sticky or flammable particulate. A washdown system keeps the ESP internals clean to help prevent fires and maintenance problems. Our durable wet ESP systems have solved difficult emission control problems for fiberglass forming and curing ovens, wood dryers, wood-fired boilers, and steel scarfing processes.

Our ThermaGrid regenerative thermal oxidizer (RTO) systems use high temperature to destroy VOC emissions within a combustion chamber. What sets it apart from other RTOs is its economical operation. It uses monolithic ceramic blocks as a heat transfer medium. The monolithic ceramic can handle dirty or particulate-laden gas flows with very little need for maintenance. ThermaGrid RTO technology has been proven effective for controlling VOC emissions from wood dryers, fiberglass curing and forming processes, paint booths, chemical and pharmaceutical processing, semiconductor manufacturing, printing processes, rubber and plastics manufacturing, and aluminum casting operations.

We have the technical expertise to engineer a fabric filter system with the proper air-to-cloth ratio, can velocity, and gas distribution to achieve the lowest possible pressure drop and longest bag life. Our experience with a wide variety of woven and felted bag fabrics allows us to select one that will be most economical and effective for your application. Engineering considerations include the fabric's ability to withstand high temperatures, exposure to acid, and abrasion.

Our deNOx SCR reactors are designed specifically to control NOx emissions on industrial applications. Our systems feature a fully integrated system design that includes modular construction, CFD modeling, a PLC-control system, a customized cleaning system, a reagent management system, and a catalyst life management system. We offer a single-source performance guarantee and equipment warranty for each reactor system.

We supply complete air pollution control systems to solve a combination of particulate, acid gas NOx, and VOC problems. We have extensive engineering and manufacturing capabilities and provide all the necessary auxiliary equipment for those systems.

Our electrostatic precipitator systems generate a corona to electrostatically charge particulate and remove it from flue gas streams. Each ESP system is designed to provide effective control of particulate emissions, while saving you money by minimizing operating costs. A unique needle/plate collection electrode design uses energy very efficiently, enabling our ESPs to operate economically at low voltage and current levels.

McGill AirClean's mobile ESP can be used to study an emission problem on site and develop an effective solution. This equipment enables the company to analyze the flue gas stream, determine ESP collection efficiencies, and collect data to size a full-scale wet or dry ESP for a customer's application. Mobile testing helps us size the full-scale system to satisfy your performance requirements. We will design an efficient, economical, properly sized system that will be large enough to handle your volume flow, yet not have more capacity than you need. A properly sized system can save you a substantial amount of money in equipment, installation, and operating costs. Should your requirements ever change, McGill AirClean's modular design makes it easy to add to the system.

Our mobile ESP can be used to study your emission problem on site and develop an effective solution. This equipment enables us to analyze your flue gas stream, determine ESP collection efficiencies, and collect data to size a full-scale wet or dry ESP system for your application.

We can test emissions on site and engineer an acid gas control system for your application. By using our mobile spray-dry scrubber in conjunction with our mobile ESP, we can demonstrate the effectiveness of a full-scale air pollution control system.
