General purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability. Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

Submersible, general purpose, top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh underwater environments. Internal electronics are isolated to minimise noise with increased bias voltage stability. Sealed to IP68 and includes integral heavy duty polyurethane cable. Available with a wide range of mountings.

ATEX and IECEx Group I & II certified. General purpose top-entry constant current accelerometer with isolated AC output. Made from robust stainless steel throughout for long term vibration analysis in harsh, hazardous gas and dust environments. Internal electronics are isolated to minimise noise with increased bias voltage stability. Sealed to IP67 and includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

General purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise. Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers. Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

ATEX and IECEx Group I & II certified. General purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh industrial environments. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise. Sealed to IP67 with industry standard two wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers. Includes 2-pin MS connector, 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

ATEX and IECEx Group II certified. Submersible, general purpose, top-entry velocity transducer with DC output. Made from robust stainless steel throughout for continuous vibration monitoring in harsh underwater environments and areas with constant moisture or condensation. Internal electronics are enclosed in a Faraday cage and isolated to minimise noise. Sealed to IP68 with industry standard two-wire 4-20mA output proportional to sensor range that can connect directly to PLC, DCS and other industrial controllers. Includes integral heavy duty polyurethane cable and is available with a wide range of mountings.

General purpose, top-entry, constant current velocity sensor with isolated AC outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Sealed to IP67 and includes 2-pin C5015 military style connector. Available with a wide range of mountings.

Ultra compact, very low mass, charge-output, side-entry accelerometer with microdot connector. Ideal for R&D and high frequency applications.

General purpose top-entry constant current accelerometer with isolated AC and temperature outputs. Made from robust stainless steel throughout for long term vibration analysis in harsh environments. Internal electronics are isolated to minimise noise with increased bias voltage stability. Sealed to IP67 and includes 4-pin M12 connector or stainless steel overbraided ETFE cable and is available with a wide range of mountings.

Top-entry, constant current accelerometer for vibration analysis at elevated temperatures. Made from robust stainless steel throughout for long term analysis in harsh environments and up to 250ºC surface temperature; as the sensor head contains no electronics. An in-line charge amplifier connected with extra high-temperature cable (265ºC) can be located 5 metres from the heat source where temperatures are 120ºC or less. A further 5 metres (or longer) of overbraided cable connects to the junction box or data collector giving an output of 100mV/g. Available with a wide range of mountings.
