NPV Unidirectional valve design provides for full guiding of gate throughout the cycle which prevents any gate distortion even in the event of back pressure

NPV Unidirectional valve design provides for full guiding of gate throughout the cycle which prevents any gate distortion even in the event of back pressure

Perimeter seating guarantees bi-directional bubble tight shutoff. Elastomer seat is mechanically retained between body halves preventing movement or separation from the body, unlike standard o-ring seated valves. Full port cavity free body design prevents de-watering of pulp stock and is ideal in slurries, powders, plastics and other solids handling applications.

DUCO Scavenger design removes cavities/pockets thus eliminating problems caused from accumulation of solids that can prevent proper cycling of valve

NPV O-Port design is generally used in heavy slurry and scaling applications. Special Electro Polished gate with machine beveled edge is standard in severe services such as phosphoric acid, green liquor and white liquor applications. Precision machining of body halves and close tolerances to gate eliminates solids build up between components ensuring proper cycling. Elastomer seated design eliminates pressure on packing in fully open and fully closed positions extending packing life. Equipped with hardened gate and cartridge seats, O-Port can be used in large scavenger applications for recycle pulper applications. Positive shutoff bidirectional valve in heavy stock applications eliminates dewatering.

The NPV HD/MD Reject Chamber Valve is designed specifically to handle the wire, staples, glass and sand typically found in recycle paper mill reject systems.

Perimeter seating guarantees bi-directional bubble tight shutoff. Cavity free body design prevents de-watering of pulp stock and is ideal in slurries, powders, plastics and other solids handling applications.

All cylinders manufactured by NPV mount directly to our valves eliminating need for an adapter plate. All gates are machined to adapt to manual or automated operation.

The NPV HD/MD Reject Chamber Valve is designed specifically to handle the wire, staples, glass and sand typically found in recycle paper mill reject systems.

For positive isolation of all transmitters to facilitate repair, calibration or replacement. Valve port is precision machined to the transmitter diaphragm dimensions, providing for a most accurate reading. Special frange design with offset bolt pattern allows valve to be bolted directly to the tank.
