Northwest Flattanks products

Standard Drillsite Water Tank (capacity app. 2345 Gallons) 17.04` of useable bed, ¼ steel plate construction, 56.5" wide x 60.375” tall, total tank length will be 18.5` long with 18" deep x 94.5" wide x 14" tall junk box built with tubing or angle & expanded metal the box will have sides for cargo control in transport, (4) horizontal tool boxes to truck fit x 24" deep x 21.5" tall 10 gauge steel plate material.

Flattank/Pickup Support Trucks - Standard Drill site Water Tank (capacity app. 950 Gallons) 114" or 9.5` of useable bed, 3/16" steel plate construction, 90" wide x 18" tall, total tank length is 12`, Weather tight tool boxes. 10 gauge steel plate material - (2) front driver horizontal boxes 48" long x 24" deep x 16" Tall.

Northwest Flattanks is manufacturing Sonic tender support trucks that can be built in ridged wall van or collapsible van styles. Flattank has water in the first 18` of bed, 12` of bed for rod racks, 6` of bed for pallet storage, 6` of bed for front pressure washer & welder mounting, small work table with drawers, shovel rack holder under welder & pressure washer mounts, welder & pressure mounting 4` in form the front sideways of each other, the whole bottom of tank is be fitted with horizontal tool boxes to truck fit, x (4), (4) 2" all corners drains with ball valves, & (1) rear center, (1) 4" gravity fill in front of drill rod stopper, 3 tie down winches, rear folding step platform 18" wide 25 ton pintle air & wiring to rear 7 prong plug, truck LED Lighting inside folding step platform, 3 led lighting pointed to rear of body.

Decon Trailer - 14000 lb GVW, 14` flat deck, 2" square railing around deck, tandem 7,000lb capacity Dextor Torflex axles, 865 hub & drums, 12` x 2" electric brakes, LT245/85R16 Load Range G - 10ply tires, 2-1/2" lunette eye on adjustable hitch plate 1" threaded steel plate, 7" x 4" x 3/8" angle frame, 3" channel cross members, 1/8" steel tread plate deck, 81" wide between fenders, ICC and DOT approved sealed lights, 60" tongue length, 7,000 lb capacity drop leg jack, safety chains, spare tire with locking mounted on tongue, 16" deck height, shovel storage, bucket storage area, 4.25" HD Pin receiver for pavement auger head, mud mixer storage area, open storage area in forward position of trailer Bulkhead - behind storage area for pressure washer protection customer- supplied and installed pressure washer 300 gallon steel water tank, bolt down, with access drain and ball valve, Decon basin bolt down.

Offering Our Flattanks standard or customized to your specs, mounted on any truck chassis, includes pickups, single axle, tandem axle (lift axle) or tri drive truck chassis. Our standard Flattanks are as follows: Standard Drillsite Water Tank (capacity app. 2100 Gallons) 21 feet of useable bed, x ¼ steel plate construction, 94.5 inches wide x 22 inches tall, total tank length is 23 feet 1 inch with 2 front verticals, Weather tight tool boxes.

Water Well Development Flattanks Trailers Flat Water tank trailer V Bottom 80 inches wide x 18 feet long (102 inches W x 23 feet L Overall) 700 gallon tank capacity 216 inches L x 37 inches W 10 inches High 3/16 inches material (1) 3 inches water fill driver side front located (1) 2 inches rear drain each, inside epoxy center support tube clean water 10 inches x 6 inches x 3 feet 16 inches rec.

Sonic Van Tender Support Trucks Radius Roof With Translucent Covering: Standard, Roof Support: Bowed, I Beam Crossmembers on 24 inch Centers, 100 inch Thick Extruded Aluminum Alloy Sidewalls, with Patented Snaplock.

Custom build your horizontal tool cabinets flush bottom design, or 2" lip turned up, building these at any length or to truck fit.

Top diamond deck plate is provided upon request & availability only.

Discharge Ports are available in all sizes our most standard are (5) total 1 in each corner & 1 in rear center size 2" with brass ball valves & cam locks.
