OCV Control Valves products

The Model 8101 is applicable anywhere it is necessary to automatically control the high level in storage tanks where the float pilot can be mounted inside the tank.

The OCV Series118/108SA surge anticipation valves are designed to be installed in a bypass line and provide protection against damaging surges that can occur in pumping systems when a pump is suddenly stopped. Unlike conventional relief valves, which open only when a high pressure wave hits, surge anticipation valves sense the precursor of the high pressure wave (pump power failure or low pressure wave) and opens in anticipation of the returning high pressure wave that follows. By opening, the valve prevents the buildup of pressure before it occurs.

The Model 1330FC is a pressure relief valve that is installed downstream of a pressure reducing valve and is located in the distribution piping in a fire protection system. If the pressure in the distribution piping should become over pressurized, the 1330FC will open and relieve the excess pressure, preventing damage.

The Model 108-2HP automatically relieves excess fire pump discharge pressure to prevent the pressure from exceeding the rating of the fire system components. It is specifically designed for those systems where the relief set point must be higher than the pressures allowed for UL-listed/FM-approved valves.

The Model 108-2SLF automatically relieves excess foam pump discharge pressure to prevent the pressure from exceeding the rating of the fire system components. The engineered SLF (sense line flush) feature assures accurate pressure control by continuously flushing the pilot sensing chamber (flow through design).
