Oniar LLC products

Trailer ID: 34. Frame type: Single beam. Cross section of loading area-m²: 2,1. Frame profile-mm: 200x200x8. Wheel hubs: 80x80 - 6. Wheels: 400/60-15,5. Suitable cranes: 6800.

Trailer ID: 134 - 137 - 142. Frame type: Double beam - Double beam - Double beam. Cross section of loading area - m2 - 2,3 - 2,3 - 2,3. Frame profile - mm - 2x(200x100x8) - 2x(200x100x8) - 2x(200x100x8). Wheel hubs: 80x80 - 6 - 80x80 - 6 - 90x90 - 8. Wheels: 400/60-15,5 - 500/50-17 - 550/45-22,5. Suitable cranes: 6800 / 8000 - 6800 / 8000 / 7500 - 6800 / 8000 / 7500 / 8750 / 8800.

Technical information - Group 2. Trailer ID: 237 - 242 / 242 R - 246 / 246 R - 246 e / 246 Re. Frame type: Double beam - Double beam extended (R) - Double beam extended (R) - Double beam extended (R). Cross section of loading area - standard poles - m2 - 2,6 - 2,6 - 2,6 - 2,6. Cross section of loading area - FW poles - m2 - ---- - 2,4 - 5 - 2,4 - 5 - 2,4 - 5. Frame profile - mm - 2x(200x120x8) - 2x(200x120x8) - 2x(200x120x8) - 2x(200x120x8). Wheel hubs - mm - 80x80 - 6 - 90x90 - 8 - 100x100 - 8 - 100x100 - 8. Wheels: 500/50-17 - 550/45-22,5 - 600/50-22,5 - 710/40-22,5 (e). Suitable cranes: 6800 / 8000 / 7500 - 6800 / 8000 / 7500 / 8750 / 8800 - 6800 / 8000 / 7500 / 8750 / 8800 - 6800 / 8000 / 7500 / 8750 / 8800.

Technical information: 6800. Maximum reach - m: 6,8. Work pressure: bar - 180 / 220. Lifting force (gross)- kNm: 48 / 60. Slewing torque (gross) - kNm: 15,5 / 19. Optimal oil flow (FIX system): l/min: 30-45. Flange rotator - kNm: 45: 45. Suitable trailers: 34 / 134 / 137 / 142 / 237 / 242. Suitable grapples: G18E / G20.

Maximum reach: m: 8,0. Work pressure: bar: 180 / 220. Lifting force (gross): kNm: 48 / 60. Slewing torque (gross): kNm:15,5 / 19. Optimal oil flow (FIX system): l/min: 30-45. Flange rotator: kNm: 45. Suitable trailers: 34 / 134 / 137 / 142 / 237 / 242. Suitable grapples: G18E / G20.

Maximum reach: m: 7,5. Work pressure: bar: 180 / 220. Lifting force (gross): kNm: 69 / 85. Slewing torque (gross): kNm: 21 / 26. Optimal oil flow (FIX system): l/min: 45-60. Optimal oil flow (LS system): l/min: 80. Flange rotator: kNm: 55. Suitable trailers: 137 / 142 / 237 / 242 / 246 / 342 / 346. Suitable grapples: G18E / G20 / G22E / G24
