5 products found

PK Pride Co LLC products

PRIDE - Drilling rig URB3A3

🔥🔥🔥Specifications🔥🔥🔥 Conditional depth of drilling, m: pipes with a diameter of 60.3 mm; 63.5 mm - 500-600 (Optionally till 1000 🔥) pipes with a diameter of 73 mm; 89 mm 300-400 (Optionally till 600 🔥) Rotor feedrate, 5200 mm Maximum lifting force, 20000 kg Maximum pressure on the face, 6000 kg Rotator type movable, continuous Maximum torque on the spindle, 8000 N*m Maximum number of revolutions per spindle,110 rpm Winch type for auxiliary operations hydraulically driven Payload of winch, 2000 kg Mast type Steel, welded with open front face Recommended bar length, 4.7 m Pressure in the system, working 16MPa. maximum 20 MPa https://www.youtube.com/watch?time_continue=64&v=_1h0Gk36IwQ

PRIDE - Drilling rig TITAN 120

Max. initial diamete, 300 mm Grade of formation for drilling 12 Max drilling depth, 200 m Dimensions, L/W/H, mm: 5500/1220/1700 Mass, 4000 kg SWIVEL Type Reducing gear box Rotative moment, (Нм) 2200 (optionally till 4400) Rotation speed, (sev/min) 0-330 Pulling force, (kg): up/down 2000 Carriage movement, 3500 (mm) HIGH-PRESSURE PUMP STATION Type Gasoline Power, 120h.p. CHASSIS Type of crawlers rubber-metal. Width of crawler, 230 mm Speed, 6 km/h

PRIDE - Drilling rig TRAILER 60

🔥🔥🔥The most popular installation in 3 continents👍👍👍 The installation can be equipped with an external control panel (except for the economy version), which allows you to control drilling when the driller is in close proximity to the wellhead. When the unit is equipped with a hydraulic gearbox rotator (maximum torque of 2000, 4000 N / m), equipped with a drilling fluid supply unit for flushing or compressed air supply for flushing and with a hammer, no swivel is required (as with URB). Category B trailer with its own passport; re-registration at the Inspectorate is not required. The unit is placed as a removable load. 2-line hydraulic system, which allows you to independently adjust the force on the face and rotation of the tool. Carriage feed - on the hydraulic cylinder or chain. Mach Initial bit diameter, 300 (mm) Rock Strength Category 12 Mach Drilling Length, 200 (m) Overall dimensions of installation, (mm): 4500 * 1800 * 1800. Installation weight 750 (kg)👨‍🔧

PRIDE - HDD 4*8

This HDD rig is designed for laying communications with trenchless way for a length of up to 100 meters, the maximum diameter of pipes and cases does not exceed 300 mm. HDD rig S2x4 due to it`s small dimensions can be work in tight urban conditions. Equipped with automatic feeding of rods and customer's wish is completed by all necessary tool. The weight of the rig 3700 (kg) Dimensions of rig (l/W / h): 3870 х 1900 х 1800 Max. Drilling length 110 (m) Max. Extension 300 (mm) 2 screw anchors Мах. Torque 2000 (Нм) Rotation speed, rev/min - I gear - 1100 Нm till 330 rev/min - II gear - 2200 Нm till 165 rev/min high-pressure pump station Engine model D-243 Diesel Hydraulic system pressure (bar) 200/140, 160/120, 150 Engine power 60 hp Drilling rods Length till 1830 (mm) Diameter 48-50 (mm) Pulling system of drilling rods Traction power, 4000 (кН) Сarriage speed, 0.2-1 (m/sec) Mast/ Automatic feeding system of rods Angle of drilling 20° Width of crawlers, 300 (mm) Speed, till 3 km/h

PRIDE - Drilling rig S-15

S-15 designed for drilling water wells, geophysical, survey, injection, horizontal directional wells. The rig can be equipped with a remote control, which allows you to control drilling when the driller is in close proximity to the wellhead. Well drilling is carried out in a rotational way by washing, blowing or lifting the destroyed rock to the surface with screws. For drilling wells in rocks of 1-9 categories of drilling capacity. When completing the rig with a hydraulic rotary reducer (maximum torque 2000, 4000 N / m), equipped with a drilling fluid supply unit for washing or supplying compressed air for purging and with a pneumatic hammer, a swivel (as in the URB) is not required. The unit can be equipped with a hydraulic auxiliary winch, hydraulic outriggers, a drilling pump and other equipment on the customer's instructions For the convenience of transportation, the s-15 can be mounted on the base of a car trailer No need to re-register in the traffic police.
