PMP Precision Valve Co. Ltd. products

A101 -1 Piece Ball Valve Reduced Bore 800 WOG 1/4` -2`.

Adjustable PTFE Packing. Investment Cast CF8M Body. PTFE Body Seal. Full Bore Design. Stainless Steel Latch Lock Handle. Blow-out Proof Stem. Solid 316 Stainless Steel Ball. Bi-Directional RPTFE Seats.

Pressure Rating PSIG. 1/4"~1" 2000. 1-1/4"~2" 1500. 2-1/2"-3" 1000. (M202).

Locking Tab Washer: Keeps Lock nut from loosening in High Cycle Automated Applications. ISO 5211 Mounting Pad: Allows Direct Actuator Mounting Eliminating Costly Brackets - Adapters. Bi-Directional RPTFE Seats. PTFE Thrust Washer. Full Bore. Live Loaded Stem Packing: Keeps packing tight avoiding leaking valves and costly shutdowns or repairs.. TFE Body Seals. TFE Stem Packing with Viton O-Ring. Investment Cast CF8M Body. Polished Solid Stainless Steel Ball.

Q104 - 2 Piece Forged Brass Full Port Ball Valve 600 WOG 1/4" - 4".

Flanged Y-Strainer: 1/2"~2" Investment cast body. 2-1/2" and larger sand casting. Designed to: ANSI B16.34. CF8M & WCB steel bodies
316 SS screens 1/4" mesh. Max. working temperature 445 F Options: Blow down valve. Various size screens and mesh liners.

Threaded ends conform to: ASME B1.20.1. Max temperature 445o F. S.S. Standard Screen 0.032. Options: Blow Down Valve, Various size screens and mesh liners. Investment cast CF8M Stainless Steel body.

Featuring low head loss, the PMP sinking ball check valve is normally installed for sewage applications to prevent back flow. Valves can be installed for either horizontal or vertical applications. The sinking ball automatically cleans itself and offers tight shut-off.  The body cover is easy to disassemble for quick maintenance

Vertical & horizontal flows. Standard EPDM Resilient seats. 200 psi Maximum Pressure.

Vertical & horizontal flows. Standard VITON Resilient seats. Temperature -4 o, F to 392 oF. Options: NBR, Metal Seats.
