ProSep Inc products

With a unique, center-located injector, ProSep’s ECLIPSE, low injection flow mixer allows for efficient mixing of small injected fluid volumes into the process flows. The ECLIPSE’s design is superior to other technologies, such as injection quills, provides homogeneous, high efficiency mixing with no lower limit on the injection fluid flow rate.

Conventional mixing valves have a valve geometry which changes the local flow direction and creates non-homogeneous and extreme local shear forces which can result in stable emulsions of wash water and crude, thus affecting the separation performance in downstream equipment.

ProSep’s high efficiency mixer, AIM, achieves efficient mixing of injected fluid with multiphase, gaseous or liquid dominant flows with a low pressure drop over the operating range. Momentum transfer creates injected fluid dispersion with high mass-transfer properties, while the annular injection ring along the pipe wall creates a homogeneous downstream process fluid.

The TORR coalescing technology, with its small footprint and ability to replace less efficient oil removal equipment, is a scalable technology that addresses future increases in water cut for offshore operators.

The CTour  process removes dispersed oil and dissolved hydrocarbon contaminants in the produced water stream through injection of condensate.
