Screwsucker - Pumping By APSCO products

Discharge Flange: 6” 125 LBS. ANSI. Capacity: (max) 2000 GPM. Head: (max) 210 ft.

Discharge Flange: 6” 125 LB. ANSI. Capacity: (max @ 1800 RPM) 1900 GPM. Head: (max @ 1800 RPM) 136 ft.

Clog resistant impeller and liner in wear resistant configuration. Impeller has large free passage of 4”. Fuel consumption is 50% lower than conventional dirty water pumps with the same free passage. Large pump capacity combined with a low engine power rating. The pump set primes very quickly even at large suction heights. The vacuum system can handle large quantities of air. Up to 59 cfm, standard is 15 cfm. Capable of pumping unscreened raw sewage water. Capable of pumping viscous liquids. The wear liner can be adjusted from outside the pump. R1 and R3 configuration. Electronic vacuum system. Pump is capable of long running times in snore conditions. Pump can dry prime down to 28 feet. Automatic start / stop system (level switching). Very low noise emission. Double shaft seal immersed in oil bath (sic/sic and carbon/ceramic). Pump unit can be stacked.

Clog resistant Impeller and liner in wear resistant configuration. Impeller has large free passage of 4`. Fuel consumption is 50% lower than conventional dirty water pumps with the same free passage. Large pump capacity combined with a low engine power rating. The pump set primes very quickly even at large suction heights. The vacuum system can handle large quantities of air. Up to 59 cfm, standard is 15 cfm. Capable of pumping unscreened raw sewage water. Capable of pumping viscous liquids. The wear liner can be adjusted from outside the pump. R3 configuration. {* Electronic vacuum system. Pump can dry prime down to 28 Feet. Automatic start / stop system (level switching). Very low noise emission. Double shaft seal immersed in oil bath (sic/sic and carbon/ceramic).

The screw / centrifugal impeller of the Hidrostal Pump, with its open channel impeller design combines the gentle action of a screw pump and the high flow rates and effciencies of a centrifugal pump. Hidrostal is the best centrifugal pump alter-native for clog free, low-shear / low emulsion pumping, at the most economic and operation cost.
