The maximum load capacity can reach 80KG. Servo direct drive, high precision and fast response, the highest accuracy can reach ±0.05e. High protection level, up to IP66. The shell is made of high-strength aluminum allov material to resist harsh environments.

High stability: military product design specifications, high-strength aluminum alloy shell, curved wind-resistant design. High precision: 300,000 photoelectric coaxial encoder servo drive, positioning accuracy up to 0.01°. Data feedback: real-time feedback on azimuth, pitch angle, focal length, and focus value. Wide rotation speed: maximum rotation speed 200° s, minimum rotation speed 0.01= s. Large angle: azimuth rotation range 0-360c, pitch rotation maximum reachable range =90°. Modular design: The modular design of the circuit board facilitates debugging, maintenance and upgrades.

High stability: military design specifications, high-strength aluminum alloy shell, spherical wind-resistant design. High precision: 300.000 photoelectric coaxial encoder, servo drive, positioning accuracy can reach 0.01°. Data feedback: real-time feedback of azimuth, pitch angle, focal length, focus value. Wide speed: maximum rotation speed 90° s. minimum speed 0.01° s. Modular design: modular design of circuit board, convenient for debugging and maintenance upgrade.

It can be equipped with infrared thermal imagers, visible light lenses, infrared laser illuminators, laser rangefmders and other equipment. It supports a variety of visible light lenses and can transmit the position, lens focal length and lens focus position in real time. The stepless speed control system makes the operation more stable and reliable: The turntable has high repeatability and positioning accuracy, up to =0.01. Supports 3D positioning function, with optional GPS. electronic compass, gyroscope and other functions. The whole machine reaches IP67 protection level and the ball chamber is nitrogen-filled, which is suitable for use in harsh environments.

Max load capacity 30kg. Max rotation speed up to 60" s. Multiple lens preset self-adaptation functions. High resetting accuracy, the best up to ±0.05° when closed-loop control. Horizontal 0—360* continuous rotation. Protection Class. Max IP67. Adopt high-strength die-cast aluminum alloy material anti harsh environment. Full closed-loop control optional. Easy to maintain with double shell design.

Max load capacity 20kg. Adopt high-precision, high-strength worm-gear driven, self-locked when power is off. High resetting accuracy, up to ±0.1°. Protection Class: Max IP66. Adopt high-strength die-cast aluminum alloy material, anti harsh environment.

Max load capacity 100kg. High resetting accuracy, can up to 0 1c closed-loop control can reach 0 05°. Adopt high-strength die-cast aluminum alloy material, anti severe environment. Protection Class: Max IP67. Adopt high-precision, high-strength worm-gear driven, self-locked when power is off.

Adopt high-precision, high-strength worm-gear driven, self-locked when power is off 2 High transmission efficiency strong load capacity. High resetting accuracy, coaxial encoder optional. Protection Class: Max IP66. Adopt high-strength die-cast aluminum alloy material anti harsh environment.
