Shark Marine Technologies Inc. products

The E-TAC was developed to further meet the needs of Combat Divers.  It is lightweight, highly portable, long duration, and can operate in any environment, from 50 meters (165′) below the surface to 15,000 meters (50,000′) above sea level.

Designed for speed and power, the Barracuda is very capable in high current applications.  Constructed using high-tech plastics, anodized aluminum and syntactic foam, it is small and maneuverable. It is also large enough to support the easy addition of mission specific accessories (e.g. sonar and video systems). All accessories fit inside the frame to avoid entanglement issues. The built in Total Navigation System, and DiveLog software, give the it full geodetic positioning and autonomous capabilities.

The Sea-Wolf V ROV was built with power and modularity in mind.  Different jobs call for different equipment, and the Sea-Wolf V was built with this idea in mind. Variable payload capacity makes adding or removing any of the Sea-Wolf’s extensive array of optional peripherals quick and easy.  The ROV’s piloting software, DiveLog, provides manual operation, assisted operation through auto-depth altitude, heading, or speed control, or point-and-click autonomous operation. The Sea-Wolf V also accommodates 2 extra thrusters, providing more power for more accurate control in inclement conditions.

Shark Marine has completed integration of Patriot 3 Maritime’s Jetboots with our DiveLog software and diver held navigation systems.

The MAKO DDS Marks a New Evolution in Diver Transportation by Combining a Propulsion Device with the Shark Marine “Navigator”, Diver Held Navigation and Sonar Imaging System. The Combination Provides a System that is Capable of Automated Flight Paths, From a Simple “Goto Target” to Complex Survey Routes, While Providing the Diver with full Navigation and Forward Looking Sonar to View and Locate Targets up to 300m (984ft ) Away. The MAKO can be flown in Manual, Semi-Autonomous and Full Autonomous Modes. Unlike Standard Diver Propulsion Vehicles The MAKO uses Vertical Thrusters that Allow it to Adjust Its Pitch / Roll and Maintain Depth While Stationary

The Aurora 4 48 VDC light offers the same dimmable 1850 lumen, even flood patterned light as the Aurora 3 model but in a more compact size.  Small and streamlined, the Aurora 4 can be easily mounted on ROV’s, Drop Cages, Dive Helmets / Masks and Pistol Grips.

Shark Marine’s SV-HD-SDI is a broadcast quality High Definition (1080i) camera utilizes a 1/3 inch CMOS CCD to provide excellent image quality. This camera also features a 10X optical zoom, manual and automatic focus, which are controlled using a hand controller.  The camera is built into a ruggedized housing and can go to depths of a max 1524 meters (5000 feet). Video transmits over fiber optics, and power and zoom control is through a wet-mateable connector.  The SV-HD-SDI measures 7.75″ x 2.8″.

Shark Marines second-generation underwater zoom camera, the SV-DSP-ZOOM2, is a high performance, digital signal processing colour camera with multiple controllable features. It utilizes a 1/4-type Exview HAD CCD to produce high quality images in both digital-zoom and slow shutter modes. The 10X optical zoom provides high detail for underwater inspections. The camera’s in-line control box provides functions for zoom, auto or manual focus, white balance and gain.

The SV-VLC2 combines many of our standard video system products into one modular topside that is affordable, rugged and easy to use.  The basic SV-VLC2 works with the entire range of Shark Marine cameras and includes power out for camera and variable light control.  The SV-VLC2 also comes standard with built in USB video capture, allowing the operator record video on any available computer.  Available built-in options include; GPS overlay, Keyboard overlay, and visibility enhancement.

The new DT101 Multibeam Profiling Sonar (i.e. Multibeam Echo Sounder) is a single instrument integrating the sonar, motion reference unit (MRU), and sound velocity sensor into one sleek and compact unit.  The DT101 requires only one cable for operating all three sensors and is a portable solution for any survey.
