Siddhi Engineers products

Specifications: Available in 0.5 hp & 1 hp. Head : up to 40 mtrs. Discharge : up to 3300 lph. Supply : 1-phase. Delivery size : 1 x 1. Winding : copper (e.c.grade). Impeller : brass. Motor body : aluminium. Available with thermal over load protector (T.O.P.).

Specifications : Available in 0.5 hp & 1 hp. Head : up to 50 mtrs. Discharge : up to 3000 lph. Supply : 1-phase. Delivery size : 1 x 1. Winding : copper (e.c.grade). Impeller : brass. Motor body : aluminium/cast iron. Available with thermal over load . Rotector (T.O.P.).

Specifications: Available in 0.5 hp. Head : up to 38 mtrs. Discharge : up to 3000 lph. Supply : 1-phase. Delivery size : 1 x 1. Winding: copper (e.c.grade). Impeller : brass. Motor body : cast iron. Available with thermal over load protector (T.O.P.).

Specifications: Head : up to 30 mtrs. Discharge : up to 500 lpm. Supply : 1-phase/ 3-phase. Delivery size : 25 x 25 & 50 x 50. Winding : copper (e.c.grade). Casting parts : graded casting. Available with thermal over load protector (t.o.p.). *also available for wide voltage range.

Specifications: Head : up to 24 mtrs. Discharge : up to 550 lpm. Supply : 1-phase/ 3-phase. Delivery size : 50 x 50 & 65 x 50. Winding : copper (e.c.grade). Casting parts : graded casting. Available with thermal over load protector (t.o.p.). *also available for wide voltage range.

Specifications: Head : up to 26 mtrs. Discharge : up to 1000 lpm. Supply : 1-phase/ 3-phase. Delivery size : 65 x 50 & 75 x 65. Winding : copper (e.c.grade). Casting parts : graded casting. Available with thermal over load protector (t.o.p.). *also available for wide voltage range.

Material of Construction: Motor shaft : aisi 410 / aisi 420. Thrust bearing : carbon plate with s.s. segment (with tilted pads). Stamping : electric sheet. Casting parts : graded casting (fg 200). Copper :e.c. grade copper (99.9% purity). Bush : leaded tin bronze (ltb-4). Fastners :stainless steel. Rubber parts : NBR

Material of Construction: Motor shaft : aisi 410 / aisi 420. Thrust bearing : carbon plate with s.s. segment (with tilted pads). Stamping : electric sheet. Casting parts : graded casting (fg 200). Copper :e.c. grade copper (99.9% purity). Bush : leaded tin bronze (ltb-4). Fastners :stainless steel. Rubber parts :NBR.

Material of Construction: Shaft : s.s. 420 / s.s. 410. Thrust bearing : carbon + ss. Stamping : stainless steel. Casting parts : graded casting. Copper : e.c. grade copper (99.9% purity). Bush : leaded tin bronze (ltb-4). Fastners : stainless steel. Motor body : stainless steel. Impeller : glass filled engineerng polymer / graded casting.

Material of Construction: Shaft : s.s. 420 / s.s. 410. Thrust bearing : carbon + ss. Stamping : stainless steel. Casting parts : graded casting. Copper : e.c. grade copper (99.9% purity). Bush : leaded tin bronze (ltb-4). Fastners : stainless steel. Motor body : stainless steel. Impeller : glass filled engineerng polymer / graded casting.
