Steel Smith products

Toggle Clamps - Model VTC2535UB - Toggle Clamps

THESE MODELS HAVE FLAG BASE FOR DRILLING AND BOLTING ONTO THE WORK POSITION . THE CLAMPING ARM EXHIBIT A MINIMUM 90 DEGREE OPENING ANGLE FOR EASY UNLOADING OF WORK PIECE .

Toggle Clamps - Vertical Hold Down Action Heavy Duty Flanged Base

Steel Smith - Model VTC-6561-A - Vertical Hold Down Action - Heavy Duty Flanged Base Toggle Clamp

Weight :1.000 kgs; Handle Moves :135o; Bar Opens :80o; Holding Capacity :X1: 4.90 kN; X2: 3.40 kN.

Steel Smith - Model VTC-120132-A - Vertical Hold Down Action - Solid Bar, Flanged Base Toggle Clamp

Weight :2.400 kgs; Handle Moves :140o; Bar Opens :85o; Holding Capacity :X1: 9.80 kN; X2: 6.40 kN.

Steel Smith - Model VTC-9092-HV-SP - Vertical Hold Down Action - Solid Bar, Straight Base Toggle Clamp

Weight :2.600 kgs; Handle Moves :140o; Bar Opens :125o; Holding Capacity :X1: 13.70 kN; X2: 8.30 kN.

Latches - Non Adjustable Medium Duty Latches

Steel Smith - Model PAH-30-502 - Non Adjustable Medium Duty Latch

Weight :0.070 kgs; Holding Capacity :4.40 kN.

Steel Smith - Model PAH-30-570 - Non Adjustable Medium Duty Latches

Weight :0.078 kgs; Holding Capacity :4.40 kN

Steel Smith - Model PAH-30-588LP - Non Adjustable Medium Duty Latches

Weight :0.085 kgs; Holding Capacity :4.40 kN.

Steel Smith - Model PAH-30-590 - Non Adjustable Medium Duty Latches

Weight :0.085 kgs; Holding Capacity :4.40kN.

Additional Locking Mechanism - Vertical Hold Down Action With Additional Locking Mechanism

Steel Smith - Model VTC-207-U-TRIG - Vertical Hold Down Action With Additional Locking Machanism

Weight :0.300 kgs; Handle Moves :62o; Bar Opens :115o; Holding Capacity :X1: 1.70 kN; X2: 1.00 kN.

Steel Smith - Model VTC-210-U-TRIG - Vertical Hold Down Action With Additional Locking Machanism

Weight :0.590 kgs; Handle Moves :58o; Bar Opens :106o; Holding Capacity :X1: 2.70 kN; X2: 1.40 kN.
