Sumip Composites Pvt Ltd products

Excellent record of resistance to corrosion and chemical attack, High impact resistance, Rigid construction, High weather resistance, Wide operating temperature range, Fire resistant, Good insulating properties, UV Protection.

Trefoil clamps are used for high voltage single core or higher sizes cables where the current rating is high & 3 core cables are not available. Sumip Trefoil Clamps are used for laying single core cables in Trefoil touching formation which helps to maintain magnetic symmetry thereby avoiding electromagnetic heating and loss of current. Sumip Trefoil clamps have been molded from virgin glassfiber filled material. Sumip Type TRE 28 Trefoil clamp has been tested satisfactorily at CPRI to withstand 50 KA short circuit fault current with spacing between Trefoil clamps kept at one meter distance.

Sumip make fiberglass light poles are constructed of polyester/epoxy resin system& fiberglass woven rowing with more then 65% of the reinforcing fiberglass in axial vertical plane which increases desired rigidity & axial strength. The pole shaft is manufactured by winding process, the winding is applied under tension and at low angel for high axial strength. Additional circular winding is provided for compression strength. This allow the flexibility of material placement, which make it the clear choice for this type of structure. Filament winding is accomplished on a machine, which winds glass fiber on a mandrel in a prescribed pattern to form a desired finished shape. A Programmable Logic Control [PLC] is used in a close loop control circuit to control machine movements. This system allows for placement to the right amount of fiberglass at the right place & orientation.

Sumip introduced this anchor base type Poles. In this design heavy duty Hot deep Galvanized Mild steel base / High grade aluminum casting base is bonded fiberglass shaft & the base is with polyurethane coat to match pole color. If require we can supply hot dip galvanized anchor bolts with shrouds also.

We make safe ladders All our ladders are designed and made to meet the applicable standards & requirements of the National (IS) as well as International standards like American National Standards Institute (ANSI), OSHA etc. OSHA has set minimum requirement with respect to the use of ladders in business and industry. Variety of ANSI safety codes are available depending on material and type of ladders.
