Superior Machines Ltd products

Middleweight Series 3000 Standard equipment includes :-460 X 267 mm precision balanced steel rollers.6ins hydraulic drive discharge auger.8 ft wide loading hopper.Minimum 35 horsepower required at PTO.Weight : 350 kg [subject to specification]
Up to 4 tonnes per hour dry rolling barley (14½ %)

Superheavyweight Series 10000 Standard equipment includes.48 ins x 12 ins dia precision balanced rollers.3 ins dia EN24T shafts with double row roller bearings.2 ½ tonne capacity loading hopper.Chain & flight discharge elevator.Heavy duty chassis with 60mm unbraked undercarriage.Hydraulic elevator positioning.Minimum 90 hp required at PTO Up to 20 tonnes per hour crimping barley (35% mc),Up to 14 tonnes per hour dry rolling barley (14½ % mc).

Superheavyweight Series 10000 Contractors Special Standard equipment includes.48 ins x 12 ins dia precision balanced rollers.
3 ins dia EN24T shafts with double row roller bearings.3 tonne nominal capacity loading hopper. 12ft x 8ft.Heavy duty chain & flight discharge elevator with hydraulic positioning.Heavy duty chassis with 60mm unbraked undercarriage.Extended chassis and U`trough discharge.IBC support stand and straps, & IBC.Minimum 110 hp required at PTO.Up to 30 tonnes per hour crimping barley (35% mc).Up to 20 tonnes per hour dry rolling barley (14½ % mc).(capacities subject to sample quality)

Solid hardened rollers with hydraulic positioning, rotary throughput calculator, three additive applicators (for pellets, nuts, concentrates). Fully galvanised, braked chassis.

48 ins x 16 ins dia precision balanced rollers. 4 ins dia EN24T shafts with double row roller bearings. 3 tonne capacity loading hopper. 12ft x 8ft. Heavy duty chain & flight discharge elevator with hydraulic positioning. Extra heavy duty chassis with twin axle 80mm unbraked undercarriage. Extended chassis with twin IBC support stand & 2 x IBC. Minimum 120 hp required at PTO. Weight: 4750 kg (subject to specification). Up to 60 tonnes per hour crimping barley (35% mc). Up to 40 tonnes per hour dry rolling barley (14½ % mc).
