Tiger-Vac Inc. products

ATEX Category 2D and 2GD Industrial Vacuum Systems - Single Phase Models

Tiger-Vac - Model EXP1-5 (4W) RE HEPA - Megaton Series Vacuum Systems for Hazardous Locations

The Megaton Series by Tiger-Vac is engineered to ensure safe and efficient recovery of combustible and conductive dusts in hazardous environments. These vacuum systems are certified for use in Class I and II, Division 1 and 2, including applications focusing on groups D, E, F, and G, and are guaranteed to meet safety standards for hazardous locations as specified under classes C1618 01 and C1618 81. The systems are compliant with NFPA 77 standards, mitigating risks associated with electrostatic discharges, thanks to their ESD Safe design. These units are versatile, supporting various industrial applications such as combustible housekeeping, metal conductive dust, 3D printing, aerospace sanding, welding fume extraction, and more. The systems are adaptable to environments ranging from cleanrooms to firing ranges, offering solutions like portable cyclone dust collectors and custom-built configurations, making them essential for maintaining safety and efficiency in industrial settings.

ATEX Category 2D and 2GD Industrial Vacuum Systems - Three Phase

Tiger-Vac - Model CD-55L (DT) EX (MFS) CAT. 2D Z21 - Megaton Series Vacuum Cleaners for Hazardous Locations

Tiger-Vac's Megaton Series offers a range of industrial vacuum cleaners uniquely designed for applications in hazardous locations. This series includes models that are explosion proof, suitable for Division 1 and Division 2 hazardous locations (HAZLOC) and also for ordinary locations (ORDLOC). These vacuums are engineered to address specific challenges found in industries such as 3D printing, aerospace, automotive, and food and pharma processing. They are adept at handling tasks like cleaning combustible dust, mercury, asbestos, lead, mold, and extracting materials from firing ranges and cleanrooms. Additionally, these vacuums are equipped for more demanding tasks like welding fume extraction, managing silica and concrete dust, and performing nuclear containment. Specialized versions can even handle the nuances of acid and corrosive substances. Portable dust collectors and custom-built solutions offer further flexibility for varying industrial requirements.

ATEX Category 2D and 2GD Industrial Vacuum Systems - Pneumatically Operated

Tiger-Vac - Model SSAT-2L (HH) AIR TIGER - Explosion-Proof Vacuum Systems for Hazardous Locations

Tiger-Vac develops vacuum systems specifically engineered for hazardous environments, designed to safely handle combustible and conductive dusts. These systems comply with various industry standards including NFPA 70 and are ESD safe to prevent electrostatic discharges. Certified under IECEx and third-party ATEX, these vacuums are intended for use in Division 1, Class I and II hazardous locations, making them ideal for challenging industrial settings. These explosion-proof vacuum systems support applications such as cleanroom operations, combustible dust housekeeping, metal conductive dust recovery, food and pharmaceutical integrated processing, and automotive industries. They serve diverse functionalities including nuclear containment, welding fume extraction, and even mercury and asbestos management. Tiger-Vac's systems are adaptable for both North American and global standards, emphasizing safety and efficiency across numerous sectors.

ATEX Category 2D and 2GD Industrial Vacuum Systems - Fuel & Solvent Recovery - Pneumatic (Air-Operated) Models

Tiger-Vac - Model SS-15 to 55 (TC) TE Series - Explosion Proof and Industrial Vacuum Systems

Tiger-Vac Inc. specializes in the design and manufacture of advanced vacuum systems tailored for hazardous locations as defined by the National Electrical Code (NFPA 70). Their products, such as the Megaton and Planet series, are engineered to safely recover combustible, conductive dusts, and flammable liquids. These vacuum systems are ESD safe, preventing electrostatic discharges and comply with NFPA 77 standards on static electricity management. Suitable for Division 1, Class I and II environments, they are certified with specifications like Ex h IIC T6 Gb and Ex h IIIC T85°C Db. The vacuums are versatile with applications ranging from 3D printing, food, and pharma processing, to heavy-duty industrial uses like welding fume extraction and combustible housekeeping. Additionally, they address specific needs such as cleanroom compatibilities and nuclear containment, ensuring comprehensive solutions across varied industries.

ATEX Category 2D and 2GD Industrial Vacuum Systems - Fuel & Solvent Recovery - Electric Models

Tiger-Vac - Model EXP1-15 to 55 (TC) TE Series - Megaton Series Explosion Proof Industrial Vacuum Systems

The Megaton Series by Tiger-Vac is a specialized range of explosion-proof industrial vacuum systems designed for hazardous environments. These vacuums are certified for Class I, Division 1 and 2, Group D, T3C, and Class II, Division 1 and 2, Groups E, F, and G locations, ensuring safety in environments with combustible or conductive dusts and flammable liquids. The systems are engineered to prevent electrostatic discharges, adhering to NFPA 77 standards for static electricity. This series addresses varied industrial applications, including 3D printing, aerospace sanding, and cleanroom tasks. They are suitable for handling metal conductive dust, hazardous substances like asbestos or mercury, and general combustive housekeeping. Designed with portability in mind, the series includes models for silica and concrete dust removal, welding fume extraction, and much more, ideal for applications in food, pharmaceutical processing, and beyond.

Mercury Recovery Vacuum Cleaners for Health & Safety

Tiger-Vac - Model MRV-8 POLY - Mercury Recovery Pharma Vacuum Cleaner

HEPA Filter - Included with an efficiency of 99.995% on 0.3 micron. Tested: IEST RP-CC001.3. H14 by MPPS method as per EN 1822 and OSHA compliant. All of our HEPA Vacuum Cleaners are Aerosol Leak Tested before leaving our facility. Designed for Mercury recovery. Thru-Flow heavy duty motor. For dry recovery only. Polyethylene recovery tank. EMI/RFI Shielded. Timer (hour counter) included. Available with an optional Variable Speed Controller. Includes Mersorb® brand carbon for the adsorption of Mercury vapors. Includes a Suction Hose, Mercury Separator and Jars with Lids. Mounted on a 4-wheel dolly for easy maneuverability. Optional Suction Cups are available.

Tiger Vac - Model MRV-8 Air Series - Mercury Recovery Pharma Vacuum Cleaner

HEPA Filter - Included with an efficiency of 99.995% on 0.3 micron. Tested: IEST RP-CC001.3. H14 by MPPS method as per EN 1822 and OSHA compliant. All of our HEPA Vacuum Cleaners are Aerosol Leak Tested before leaving our facility. Designed for Mercury recovery. Pneumatically (air) operated. For dry recovery only. Polyethylene recovery tank. Includes Mersorb® brand carbon for the adsorption of Mercury vapors. Includes a Suction Hose, Mercury Separator and Jars with Lids. Mounted on a 4-wheel dolly for easy maneuverability. Optional Suction Cups are available.

Tiger-Vac - Model MRV-900 (HMR) - Haz-Mat Response - Mercury Recovery Vacuum Cleaner

HEPA Filter - Included with an efficiency of 99.995% on 0.3 micron. Tested: IEST RP-CC001.3. H14 by MPPS method as per EN 1822 and OSHA compliant. All of our HEPA Vacuum Cleaners are Aerosol Leak Tested before leaving our facility. Cleanroom compatible with ISO Class 4 (former Class 10). Can be used in the pharmaceutical industry. Designed for Mercury recovery. Thru-Flow heavy duty motor. For dry recovery only. Stainless steel recovery tank. EMI/RFI Shielded. Timer (hour counter) included. Available with an optional Variable Speed Controller. Includes Mersorb brand carbon for the adsorption of Mercury vapors. Includes a Suction Hose, Mercury Separator and Jars with Lids. Includes a complete tool kit. Mounted on a 4-wheel dolly for easy maneuverability.

Tiger-Vac - Model MRV-1000 SS Series - Pharma - Mercury Recovery Vacuum Cleaner

Stainless steel SAE 304 recovery tank. These units contain a true HEPA Filter (H14) located upstream of the motor and a true ULPA Filter (U15) located downstream of the motor. These units are designed for mercury recovery and include Mersorb brand activated carbon for the adsorption of mercury vapors. A mercury separator and jars with lids are included. This unit are EMI/RFI shielded. All of our HEPA/ULPA vacuum cleaner are Aerosol Leak Tested before leaving our facility.

Tiger-Vac - Model MRV-16 (4W) SS - Pharma - Mercury Recovery Vacuum Cleaner

HEPA Filter - Included with an efficiency of 99.995% on 0.3 micron. Tested: IEST RP-CC001.3. H14 by MPPS method as per EN 1822 and OSHA compliant. All of our HEPA Vacuum Cleaners are Aerosol Leak Tested before leaving our facility. *Cleanroom compatible with ISO Class 4 (former Class 10). Can be used in the pharmaceutical industry. Designed for Mercury recovery. By-Pass heavy duty motor. For wet and dry recovery. Stainless steel recovery tank. Autoclavable recovery tank available. EMI/RFI Shielded. Timer (hour counter) included. Includes Mersorb® brand carbon for the adsorption of Mercury vapors. Includes a Suction Hose, Mercury Separator and Jars with Lids. Mounted on a 4-wheel dolly for easy maneuverability.
