VBC srl products

5 blades vertical cutting bar 500 mm each blade (working cut 2,30 mt). Vertical max. working cut: 5,50 mt. Lower hydraulic tilt adjustment with 1 piston. Upper hydraulic tilt adjustment with 1 piston. Steel frame. 80 lt. tank unit. Electric control. Resting platform. Machine weight 500 kg. 4 blades horizontal cutting bar 500 mm each blade (working cut 1,80 mt). Horizontal max. working cut: 3,80 mt. Hydraulic height adjustment with 1 piston. Horizontal cutting bar hydraulic adjustment with 1 piston. 80 lt. tank unit. Resting platform.

5 blades vertical cutting bar 500 mm each blade (working cut 2,30 mt). Vertical max. working cut: 6,00 mt. Horizontal max. working cut: 4,00 mt. Lower hydraulic tilt adjustment with 1 piston. Hydraulic height adjustment with 1 piston. Upper hydraulic tilt adjustment with 2 piston. Steel frame. 180 lt. tank unit. Electric control. Resting platform. Machine weight 450 kg.

180° double hydraulic ram with two hydraulic cylinders Tank with pump. Three point hitch safety frame attachment. Limit switch brake. Hydraulic lock.

4 blades vertical bar (working cut of 1600 mm). Upper cutting bars with 2 blades (working cut of 800 mm). Hydraulic tilt adjustment with 1 piston. Hydraulic height adjustment with 1 piston. Upper bar hydraulic adjustment with 1 piston. Side bar (shifting) hydraulic adjustment with 1 piston. Antishock on vertical bar Special tempered 420 mm steel blades. 5-controls hydraulic distributor with blades speed regulator. Powered by 2 hydraulic engines (it requires 150 bar pressure and 22 litres/ min oil). Pipes equipped. Stainless steel cutting part. Machine weight 170 kg.

Gyroscopic machine for Pergola, espalier system and Guyot. Vertical bar with a double blade cutting bar (working cut of 1600 mm). Horizontal bar with a double blade cutting bar (working cut of 850 mm). Hydraulic tilt adjustment with 1 piston. Hydraulic height adjustment with 1 piston. Hydraulic adjustment of the head bar with 1 piston. Hydraulic adjustment of the side bar with 1 piston. Antishock on horizontal bars 5-controls hydraulic distributor. Powered by 2 hydraulic engines (it required 150 bar pressure and 22 litres/min of oil). Equipped with piping. Machine weight 200 kg.

Vertical bar with single blade cutting bar (working cut 2000 mm) Upper bar with single blade cutting bar (working cut 850 mm) Hydraulic tilt adjustment with 1 piston Hydraulic height adjustment with 1 piston Hydraulic upper bar adjustment with 1 piston Side bar (shifting) hydraulic adjustment with 1 piston Antishock on vertical bar 5-controls hydraulic distributor Powered by 1 hydraulic engine (it requires 150 bar pressure and 16 litres/min oil) Pipes equipped Iron main frame Machine weight 160 kg GALLERY ACCESSORI.

Vertical bar with single blade cutting bar (working cut 2000 mm) Upper bar with single blade cutting bar (working cut 850 mm) Lower inclination hydraulic setting with 1 piston Hydraulic height adjustment by 1 piston Hydraulic adjustment of the upper bar by 1 piston Upper inclination hydraulic setting with 1 piston Safety device with gas shock absorber for the upper cutting blades complete with 90° rotation joint to close the machine for transportation Antishock on vertical bar 5-controls hydraulic distributor Powered by 2 hydraulic engines Iron main frame Pipes equipped Machine weight 160 kg GALLERY ACCESSORI.
