Versa-Drill by Laibe Corporation products

Custom 6x8 two man carrier with center man drive PTO Powered by CAT C18 Australian load share compliant

Custom 6x8 two man carrier with center man drive PTO Powered by CAT C18 Australian Load Share Compliant

Custom 6x8 two man carrier with center man drive PTO Powered by CAT C18 Australian load share compliant

Two axial piston hydrastatic pumps power the vehicle tracks and tophead or mud pump mud independently. An axial piston load sense pump powers the feed, winch, auxiliary and set-up functions. A cast iron gear pump provides the charge pressure and flow to circulate fresh oil into the hydrastatic pump circuits.

Peterbilt Model 348 6x6 (all wheel drive) chassis. Single output, full power transfer case road/PTO shift from truck cab. Mounted on 2 hole gear box, truck engine/transfer case powered Feed, winch, auxiliary and set-up functions are powered by 2 axial piston load sense pumps. Rotation is a closed loop circuit powered by a variable displacement piston pump

Mounting Peterbilt Model 367 6x4 chassis. GVWR 68,000 lbs . Cummins ISX15 (600 HP). Deck Engine Power Pack . CAT C18 (630 HP) with dedicated 150 gallon fuel tank (includes fuel cooler).  Combination Compressor Clutch/Pump Drive Box. Air compressor clutch engage/disengage (manually operated) and hydraulic pump gear box

Mounting Peterbilt Model 367 6x4 chassis. Power Distribution  Drill/truck single-power source with exclusive Versa-Drill power distribution gearbox/pump drive, provides direct coupled thru-drive to power rig hydraulics and Ingersoll-Rand/Doosan screw air compressor
