ZERMA Machinery & Recycling Technology products

The ZSS shredders are single shaft shredders with a powerful two speed swing ram design eliminating the risk of blocking and wearing out of internal guide rails. The machine is very versatile and can be used for shredding of all kinds of input materials and is well suited for different industries.The 457 mm diameter rotors ranging form 850 to 2000 mm width are driven by one or two oversized gearboxes. The hydraulic power pack is well integrated into the machine housing to save space and protect it from damage but still easy to access or remove for maintenance.The standard E rotor features the proven ZERMA knife and knife holder design, as well as outboard bearings and a hydraulically operated screen cradle.The machines can be tailored to various applications with cooling or hard facing and other wear options

The ZIS series shredders are single shaft shredders with a large internal volume. The redesigned hydraulic pusher system creates about 35% more space in the cutting chamber while increasing the power and speed of the ram itself. The machines are equipped with a 457 mm diameter ZERMA E rotor with widths ranging from 1200 to 2000 mm.As on the ZSS machines the rotor is driven via an oversized gearbox. The completely closed welded steel housing increases the stability and avoids material spillage.The ZIS inherits all of the advantages of the ZERMA knife and knife holder design as well as standard features such as outboard bearings, hydraulic screen cradle, it`s easy maintainability and advanced controls.

The ZBS series shredders are single shaft shredders with a tangential infeed to eliminate the need for a hydraulic feeding system. The Space saving and maneuverable design combined with the *plug and play* controls make this machine very flexible and ready to go in no time. Like its bigger brothers in the ZS series they are equipped with outboard bearings, 310 mm diameter flat E rotors with 600 or 850 mm width driven by an oversized geared motor. Utilizing the proven ZERMA knife holder and knife design. The user friendly design makes cleaning and maintenance work a breeze. The low speed of 60 rpm combined with the compact design of the ZBS shredders makes it possible to shred lumps at a relatively low noise level. The machines can be fed manually or by conveyor, material discharge can be done via conveyor or into a drop box.

The heavy duty granulators of the GSH 350 and 500 series offer a wide array of different rotor designs with widths ranging from 500 mm to 1000 mm with a diameter of 350 and 500 mm respectively. The completely welded heavy steel construction is designed to to withstand the most demanding and universal applications. Rotor bearings, knife mounts and rotor shaft are oversized.The standard V-cut creates a high quality regrind with a very low percentage of fines in the output material. The removable third stator blade is acting as a deflector wedge and allows the machine to be quickly adjusted to different application scenarios.Other standard features include easily replaceable wear plates in the cutting chamber as well as outboard bearings reducing the risk of contamination.

The heavy duty granulators of the GSH 600 and 700 series offer a wide array of different rotor designs with widths ranging from 800 mm to 1000 mm with a diameter of 600 and 700 mm. The completely welded heavy steel construction is designed to to withstand the most demanding and universal applications. Rotor bearings, knife mounts and rotor shaft are oversized.The standard V-cut creates a high quality regrind with a very low percentage of fines in the output material. The removable third stator blade is acting as a deflector wedge and allows the machine to be quickly adjusted to different application scenarios.Other standard features include easily replaceable wear plates in the cutting chamber as well as outboard bearings reducing the risk of contamination.

The slow speed granulators in the GSL 180 range feature a staggered 180 mm diameter rotor with widths ranging from 180 to 430 mm. The rotor is directly driven by a geared motor. The low rotor speed reduces the noise level of the machine and creates less dust while grinding. The special design knives of the GSL series can be sharpened easily and do not need adjustment afterwards.The material is fed via a sound absorbing feed hopper that can be tailored to fit various applications and feeding ways. Depending on the requirements the machines can be fitted with a wide variety of hoppers, they are mounted on either low or high level base frames with matching suction bins or bag filling adapters. Quick snap fasteners and hand screws make access to the machine for cleaning and maintenance fast and easy.

The slow speed granulators in the GSL 200 range feature a staggered 200 mm diameter rotor with widths ranging from 180 to 500 mm. The rotor is directly driven by a geared motor. The low rotor speed reduces the noise level of the machine and creates less dust while grinding. The special design knives of the GSL series can be sharpened easily and do not need adjustment afterwards.The material is fed via a sound absorbing feed hopper that can be tailored to fit various applications and feeding ways. Depending on the requirements the machines can be fitted with a wide variety of hoppers, they are mounted on either low or high level base frames with matching suction bins or bag filling adapters. Quick snap fasteners and hand screws make access to the machine for cleaning and maintenance fast and easy.

For the GSE 300 series different rotor designs are available in widths ranging from 300 mm to 1400 mm with a diameter of 300 mm. The completely welded cutting chamber in conjunction with the `V` type rotor design ensures dependability in operation and universal application use.The housing design offers easy and quick access to the cutting chamber during rotor and stator knife changes, servicing or screen changes.

TFor the GSE 500 series different rotor designs are available in widths ranging from 500 mm to 1400 mm with a diameter of 500 mm. The completely welded cutting chamber in conjunction with the `V` type rotor design ensures dependability in operation and universal application use.The housing design offers easy and quick access to the cutting chamber during rotor and stator knife changes, servicing or screen changes.

The GSC compact/sound proof granulators are designed with a complete sound proof enclosure resulting in an extremely quiet operation.Different rotor designs are available in widths ranging from 300 mm to 1400 mm with a diameter of 300 mm. The completely welded cutting chamber in conjunction with the `V` type rotor design ensures dependability in operation and universal application use.While it delivers excellent sound proofing capabilities, it still offers easy and quick access to the cutting chamber during rotor and stator knife changes, servicing or screen changes.The sound dampening material used in these machines is based on the latest technological research.
