Zetkama Sp. z o.o. products

Stop Valves

Zetkama - Model zGLO Fig. 208 - Stop Valve

Material: Forged steel. Nominal pressure: ANSI class 150, 300, 600. Nominal diameter: 15-50 mm. Temperature range: -29...+425°C.

Zetkama - Model zGLO Fig. 213 - Stop Valve

Material: Forged steel. Nominal pressure: ANSI class 800. Nominal diameter: 15-50 mm. Temperature range: -29...+425°C.

Safety Valves

Zetkama - Model zARMAK Fig. 600 - Safety Valve

Material: Cast steel, cast stainless steel. Nominal pressure: ANSI class 150, 300L, 300, 600. Nominal diameter: 1"-8". Temperature range: -196…+538°C.

Control Valves

Zetkama - Model zCON Fig. 236 - Bellow Control Valve with Pneumatic Actuator

Material: Grey cast iron, nodular cast iron, cast iron, cast steel, cast stainless steel. Nominal pressure: 16 - 40 bar. Nominal diameter: 15-150 mm. Temperature range: -10…+400°C.

Check Valves

Zetkama - Model Fig. 275 - Check Valve

Material: Brass, stainless steel. Nominal pressure: 16, 40 bar. Nominal diameter: 15-300 mm. Temperature range: -40…300°C.

Zetkama - Model zCHE Fig. 287 - Check Valve

Material: Grey cast iron, nodular cast iron, cast steel, cast stainless steel. Nominal pressure: 6, 10, 16, 25, 40 bar. Nominal diameter: 15-300 mm. Temperature range: -60…450°C.

Strainers

Zetkama - Model zSTRA Fig. 821 - Strainer

Almost none of the fluids that flow through a pipeline are perfectly clear – free of pollution and other kinds of contamination. Those unwanted particles can cause a major damage to the whole pipeline system, which as a result can force the facility to limit or stop the flow of liquid. That is why strainers are an obligatory part of shipbuilding, as well as heating, steam and even power engineering installations.

Zetkama - Model zSTRA Fig. 823 - Strainer

Material: Grey cast iron. Nominal pressure: 16 bar. Nominal diameter: 10-80 mm. Temperature range: -10…+200°C.

Static Balancing Valves

Zetkama - Model zSTA Fig. 221 - Static Balancing Valve

Material: Brass. Nominal pressure: 25 bar. Nominal diameter: 15-50 mm. Temperature range: -10…+120°C.

Zetkama - Model zSTA Fig. 447 - Static Balancing Valve

Material: Grey cast iron, nodular cast iron. Nominal pressure: 16 bar. Nominal diameter: 40-400 mm. Temperature range: -10…+120°C.
