Zhejiang Wei Chi Light Industry Machinery Co., LTD. products

This machine is suitable for filling and seaming the can (tinplate) of non-carbonated beverage such as juice, tea, protein drink and canned food, The capacity is 100-600 cans per minute.

This machine is used to seam the beer and other carbonated beverage after it is filled. The capacity is 25 – 45 cans/min. The machine is divided into two parts - filling and can sealing. The filling part adopts isobaric filling method. In order to prevent the volatilization of CO2 in the liquid, the temperature is around 4℃; The sealing part adopts a double - wheel progressive seal.

This machine is suitable for fruit juice beverage, tea beverage, carbonated beverage, protein beverage, canned beverage and canned goods seaming. The production capacity is 50-250 cans per minute, which is the preferred product for a certain scale beverage factory and canned food factory. In the process of the sealing, the drive, the cans support system and the sealing movement are all mechanical transmission, and the seal adopts the double seal of double rolling wheel.

This machine is suitable for the filling and sealing cans(tinplate)of materials such as jam, ketchup, chili sauce, condensed milk, etc., which have sticky, high concentration, pulp or granule. The production capacity of 80-400 cans per minute is the preferred product of a certain scale canned food factory. The whole machine is divided into two positions, filling and sealing, filling is the principle of piston filling, the liquid level is controlled by quantitative form, and the material temperature is usually filled with high temperature.

The filled cans are sended by the can claw of the rotating cylinder to  the sealing head, the falling caps device detect the cans and fall caps down and push it under the head.The cylinder support the vacuum cover to pin the head seal ring to form a seal space,and automatic vacuum and nitrogen filling,then the can support cylinder pin the can to pin the pressure head.Finally do the first and the second sealing, the sealed cans will be beated by the beating device and pass though the can convey device sent to the convey belt.

This machine is suitable for the sealing of products such as sauce, condensed milk, canned fruit and canned meat. The production capacity of 80-100 cans per minute is the preferred product of a certain scale canned food factory. The sealing process is divided into two processes: pre-sealing and sealing, and the vacuum pump system can be used to extract the vacuum and guarantee the quality of the contents.

This machine is suitable for fruit juice beverage, tea beverage, protein beverage, canned soup, etc non-carboned beverage., which can be used cans(tinplate) as the outer packing material. The production capacity of 30 to 150 cans per minute is the preferred product of a certain scale beverage factory and canned food factory. Filling adopts a normal pressure filling method, the liquid level is controlled by the liquid level filling principle, the material temperature is applicable to normal temperature filling or high temperature filling.

This machine can be used in cans (tinplate), glass bottles as outer packing materials, such as corn, green beans, coconut fruit, fruit cubes, meat granules, etc. The production capacity is 0-400cans per minute, which is the first choice of a certain scale beverage factory and canned food factory.

This machine is suitable for automatic can unloading the outer packages material is tinplate,aluminium can.The production capacity is 0-300cans per minute,is a first production for a certain scale beverage, canned food factory.

This machine is suitable for automatic loading and unloading of round containers (PE, tin, aluminum cans, glass bottles) as the packaging of outer packing materials. The production capacity is 0-300 cans per minute, which is the preferred product of a certain scale beverage factory and canned food factory. This machine is made up of loading and unloading cage parts,during the whole process send out cans automatically, automatic loading and unloading cages,take high temperature resistant plate in place manually, move the sterilization cage to operate and move the traveling block manually.
