Zxonic Technology Inc. products

Type 1029 diffuse-field microphone is designed for random-incidence measuremnts over 3.15 Hz to 12.5 kHz. TEDS functionality is available.

ZX7500 is engineered for precision and portability, it combines the functionality of a Class 2 sound level meter and a personal noise dosimeter in a compact and durable design. Compliant with IEC 61252, IEC61672-1 Class 2 and IEC61620-1 Class 2, ZX7500 offers advanced measurement, with modular design, wireless data transmission, and audio recording for spectral analysis. With IP65-rated protection and intrinsic safety certification, the ZX7500 is ideal for reliable use in demanding industrial and occupational environments.

Type 1003 Series are compliant to IEC 61094 WS microphone standards. Requiring a externaly polarization voltage of 200 V, Type 1003 series provide a precision wide measuring range of 20 to 162 dB. The unit is assembled in clean-room environment. Each microphone and preamplifier can be identified by a printed type number and a unique serial number.

Type 1023 is designed for high-precision, free-field measurements where a microphone with high sensitivity is required. The 1023 Series measure from 3.15 Hz up to 40 kHz, and is compatible with CCLD and classic-type preamplifiers, offering flexibility for various measurement setups.

The Type 1031 Series consists of pre-polarized, pre-assembled 1/4″ free-field microphone sets. Designed for high-level and high-frequency measurements, the 1031 Series offers a wide frequency range from 3.15 Hz to 80 kHz and a dynamic range from 40 to 165 dB. As a cost-effective alternative, the Type 1035 Series also features pre-polarized, pre-assembled 1/4″ free-field microphone sets. While optimized for affordability, the 1035 Series provides a frequency range of up to 20 kHz and a dynamic range from 40 to 167 dB. The unit is assembled in clean-room environment. Each microphone and preamplifier can be identified by a printed type number and a unique serial number. The unit has TEDS, which means that information about the serial number, type and sensitivity is stored within it.

The Type 1035 Series offers pre-polarized, pre-assembled ¼″ free-field microphone sets designed for general-purpose sound measurement applications. Engineered as a cost-effective solution, the 1035 Series provides a frequency range of 5 Hz to 20 kHz and an exceptionally wide dynamic range from 40 to 167 dB. It is ideal for users who require reliable, compact microphones for moderate to high sound pressure levels, without compromising measurement quality. The unit is assembled in clean-room environment. Each microphone and preamplifier can be identified by a printed type number and a unique serial number. The unit has TEDS, which means that information about the serial number, type and sensitivity is stored within it.

The Type 1011 Series are high sensitivity, pre-polarized, 1″ free-field microphone sets. Designed for low-level measurements, the 1011 Series offers a dynamic range from 6.5 to 137 dB.
The unit is assembled in clean-room environment. Each microphone and preamplifier can be identified by a printed type number and a unique serial number. The unit has TEDS available, which means that information about the serial number, type and sensitivity is stored within it.

The 1004 Series are pressure-field, externally polarized microphone sets, designed for high precision coupler measurements. The 1004 Series measure from 3.15 Hz to 20 kHz, and is compatible with only classic-type preamplifiers. Type 1004 Series are compliant to IEC 61094 WS microphone standards. Requiring a externaly polarization voltage of 200 V. Type 1004 series provide a precision wide measuring range of 20 to 162 dB.

The 1026 Series are pressure-field, prepolarized microphone sets, designed for high precision acoustic coupler measurements. The 1026 Series measure from 3.15 Hz to 20 kHz, and has TEDS available. Type 1026 Series are pressure-field, prepolarized microphone sets, designed for cost effective acoustic coupler measurements. Type 1026 series provide a precision wide measuring range of 20 to 161 dB.

Type 1036 is designed for high-level, high frequency pressure-field measurements in confined spaces. The 1036 Series offer a frequency range of 3.15 Hz to 70 kHz and measure from 53 to 176 dB, and is pre-assembled with CCLD preamplifiers only. The Type 1036 Series offers pre-polarized, pre-assembled ¼″ pressure-field microphone sets designed for high-level and high frequency measurements. Compact and robust, the Type 1036 Series delivers a wide frequency range from 3.15 Hz to 70 kHz and a dynamic range spanning 53 to 176 dB, making it ideal for demanding acoustic environments such as impulse noise, transducer testing, and ultrasonic applications.
