Seismic Equipment for P-Wave Tomography up to 1000 m

We developed a prototype of a new P-wave sparker borehole source and digital hydrophone string.

SBS1000 Magnum | P-Wave Sparker Borehole Source

The borehole source SBS1000 Magnum is designed for P-wave tomography between boreholes up to 1000 m depth. The source consists of three parts housing the complete high-voltage power supply for charging up to about 3 KV. The source can be connected to a GO-4 cable head and a standard logging unit (4-conductor cable). The unit is powered from surface by means of a 230 VAC power supply.

BHC1000 | Digital Hydrophone String

The hydrophone string BHC1000 is a fully digitized borehole receiver unit running on 4-conductor cable. The system consists of max. 24 hydrophones moulded to a multicore cable. A digitization unit is placed on top of the string and can be connected to the standard 4-conductor cable.  At surface a control unit is connected to the logging winch and directly to laptop.
