Liquiline - Model CM72 -1-Channel Transmitter Compact
Single-parameter field device for hazardous and non-hazardous applications in all industries. The Liquiline Compact CM72 is a small transmitter for Memosens sensors. It is the right choice for you if installation space is limited and you don`t need the flexibility of a multiparameter device. Together with the sensor, it fits into most assemblies and couldn`t be easier to install. The measuring parameter and measuring range are already defined during the ordering process, making the CM72 immediately ready for use with a high degree of safety against operating errors.
-
Space-saving installation:
The two-wire device fits inside an assembly and does not require its own power supply. -
Fast start-up:
Thanks to its fixed configuration, the CM72 does not have to be commissioned and can quickly start its work. -
Benefit from all the advantages of Memosens technology:
Memosens sensors offer you the safest data transmission, the highest measured value availability and total ease of use. -
On-site diagnostics:
The status of the transmitter and the connected sensor are indicated with a red/green LED. -
Suitable for all locations:
Whether your measuring point is exposed to dust, vapor, rain, snow, heat or cold, the CM72 will always be exactly the right transmitter for you.
Liquiline Compact CM72 can be used in all industries and their utilities and supports all sensors with the blue Memosens plug-in head:
-
pH sensors
-
ORP sensors
-
Conductivity sensors
-
Oxygen sensors
-
Chlorine sensors
The measurement parameter and range are specified when ordering and can not be changed afterwards.
The 2-wire device features the following interface:
-
4...20 mA
With its international explosion protection approvals, such as IECEx, ATEX, and CSA, CM72 is suitable for hazardous area use.
-
Measuring principle
Glass electrode
-
Measuring principle
Glass electrode
-
Application
The device with its robust and very small housing is designed for the following applications:
"Chemical processes
"Pharmaceutical industry
"Applications in hazardous areas -
Installation
Connection of digital sensors with Memosens-Protocol
-
Characteristic
Liquiline CM72 is a fixed configured two-wire transmitter for all areas of process engineering.
-
Design
peek housing size 115x19mm
-
Material
PEEK
-
Dimension
peek housing size 115x19mm
-
Connection
Connection of digital sensors with Memosens-Protocol
-
Ingres protection
IP67, IP68, NEMA Type 6 enclosure
-
Input
One channel transmitter
-
Output
4-20 mA
-
Additional certifications
CE, CSA C/US GP
