XCH - Model XCH-150SD -150L Low Temperature Laboratory Stability Test Chamber for Medicine
This 150L temperature and humidity test chamber, high quality stability chamber, using advanced high-quality components and manufacturing technology, stable and reliable performance, suitable for GMP certified users. Creates a temperature, humidity, light environment for drug, medicine and other products fields stability evaluation. Suitable for accelerated testing, long-term testing, wet test, climatic test and strong light irradiation test.
The Single Door Medicine Drug Stability Environmental Testing Chamber, using the latest air duct system design, the uniformity of temperature and humidity in different positions in the box is good; Integral polyurethane foaming technology, good heat preservation and moisturizing performance.
- Temperature Control: Temperature Fluctuation ≤ ±0.5?,Temperature Deviation ≤ ±1.0?
- TEMP Range: 10~65?
- Humidity Range: 20~95%
- Fluctuation: <±3.0%RH
- Environment temperature: +5~35?
- Temperature Control: Temperature Fluctuation ≤ ±0.5?,Temperature Deviation ≤ ±1.0?
- Structure Design: Adopt the latest airduct system design achieves good uniform of temperature and humidiy form different parts inside the chamber.
- Chamber Material: The liner is made of mirror stainless steel 304, no pollution source, easy to clean.
- Refrigerating System: Two sets original imported fully enclosed industrial compressor, high efficiency, low noise, ensure the long-term continuous operation of equipment.
- Humidity System: Original imported capacitive humidity sensor, direct detection of humidity,maintenance-free.
- Control System: Color touch screen temperature and humidity controller,High control accuracy, With three levels permission,audit trail.
- Safety device: compressor overheat and over-pressure overload protection, Fan overheat protection, water shortage protection.
- Dual Protection: Equipped with double insurance dry fire protection system, equipped with independent over-temperature protection system, can automatically cut off the power supply.
- Data Record: Equipped with data collection system conform to GMP requirements,Needle micro printer and USB output port as standard.
- Live Alarm: Temperature and humidity upper limit deviation alarm, independent over-temperature alarm.
- Meet a criterion: Meet ICHQ1A(R2), Chinese Pharmacopoeia 2020 edition.
- Installed Power: AC220V±10% 50HZ
- SMS alarm: Optional
- Advantages
- High performance, low noise
- High sensitivity, low annual drift
- No pollution source
- Easy to clean
Medicine Stability Testing Chamber apply to investigate the stability of drug substances and preparations, suitable for GMP and CGMP certified users.
