Dory - Model YFJ-H200 -2``-8`` Butt Welding Ends Valve Test Bench
Find the suitable valve test bench to test your valves. Valve Types: Gate/Globe/Check/Ball/Plug Valves etc. Size Range: 2``-8`` DN50-DN200. Pressure Range: Class 150-Class1500. Valve End Type: Flanged RF/RTJ.
Most popular related searches
valve testing
stainless steel tube
data acquisition system
globe check valve
ball check valve
hydraulic press
blind flange
plug valve
flange adaptor
safety testing
- Designed to test Gate,Globe,Check,Ball and Control Valves
- Size range: 2’’-8’’ DN50-DN200
- Pressure range: Class 150-Class2500 PN16-PN420 ( Pressure to be confirmed as different customers require different pressure , customization services available )
- Hydraulic Pressing Clamping system with blind flange adaptors ensure the positive seals of the valve flanges.
- Stainless steel tubes and pipelines available
- With interlock functions for safety
- Testing fluid by water or air ,water with a corrosion inhibitor, according to international valve testing& Inspection standard like API598, API6D,MSS-SP-70,ASME B16.34,MSS SP-85,FCI 70-2 etc
- Recycle water tanks
- Air driven liquid booster pump(Maximator or Haskel)
- Data acquisition system is available, including PLC,Touch screen, Printer,with test graphs & reports.
