NOSHOK - Model 2020/2120 Series -2-Valve Liquid Level Manifold Valves Hard Seat & Soft Seat
FromNoshok, Inc.
Designed for use with differential pressure transmitters in liquid level applications. Available in either single flange or double flange connection for direct installation. 100% helium leak tested to 1 x 10-4 ml/s for guaranteed performance and reliability. 2020 Series hard seat valves have 10,000 psi pressure rating @ 200 °F. 2120 Series soft seat valves have 6,000 psi pressure rating @ 200 °F. 2120 Series valves also feature a replaceable Delrin seat, and straight through porting for bidirectional, high capacity flow and easy roddable cleaning.
Most popular related searches
soft seated valve
helium leak detection system
differential pressure transmitter
stainless steel flange
manifold valve
pressure transmitter
helium test
corrosion protection
- Blow-out proof stem provides a secondary stem seal in the full open position
- FKM o-ring seal and PTFE back-up ring below the stem threads to protect from corrosion and galling; PTFE or Grafoil® packing optional
- All stems are 316 stainless steel
- All stem threads are rolled for strength and ease of operation
- One-piece bonnet with a metal-to-metal seal to the valve body below the bonnet threads
- Slotted spring pin to prevent accidental loosening
- Vinyl dust caps for bonnets and stems (non-packing)
- Materials: Zinc-nickel plated steel, electropolished 316 stainless steel
- Connections: Flange-flange, 1/2" NPT-flange
- Pressure ratings*: Hard Seat: 10,000 psi @ 200 °F
- Soft Seat: 6,000 psi @ 200 °F
- Orifice size: 0.187"
- Flow coefficient: Hard Seat: CV 0.44
- Soft Seat: CV 0.76
- Stem seal & type: All 316 stainless steel stems with FKM o-ring and PTFE back-up ring below the threads, PTFE or Grafoil® packing optional
- Options: Panel mountings, o-ring materials, handles, packings, regulating stem and stem tips
- Weight: Approximately 5.5 lb.
