TECVAL - Model MB-2.5DT -2-Way 5-Valve Transmitter Direct Coupling Manifold

TECVAL MB-2.5DT manifolds are designed to work with fluids under high pressure and/or high temperature service. You can select among three different distribution diagrams where five valves command two pressure lines, a by-pass and two purge lines with 1/4” NPT female outflow. The coupling is manufactured according to DIN 19213. Four screw 7/16” UNF and two PTFE joints to assemble the transmitter are supplied.
