LMT, Inc.
Vaxteel - Model ST Series -2500 Gallon Vacuum Tanks
FromLMT, Inc.
Standard one-compartment 1/4` carbon steel vacuum tank fully equipped for septic service, wastewater hauling and waste cooking oil collection. ST Series tanks are available with a wide variety of options and customization.
Most popular related searches
vacuum tank
vacuum pressure gauge
waste cooking oil collection
pressure relief valve
vacuum pump system
cooking oil collection
waste cooking oil
pressure vacuum relief valve
relief valve
pressure gauge
- Single Compartment 1/4" A36 Carbon Steel Vacuum Tank
- Two (2) Standard Internal Anti-Surge Baffles*
- Full-Length Detachable Hose Trays constructed with 12 Ga. A36 Carbon Steel
- Full-Length Rails constructed with 1/4" A36 Carbon Steel (available straight or tapered)
- Secondary Shutoff: 10 Gallon, 1/4" Carbon Steel
- Primary Shutoff: 12" Low-Profile, 1/4" Carbon Steel
- Top Manway: 20"W x 12" Neck, 1/4" Carbon Steel, 6 Wing Nut
- Rear Manway: 20"W x 12" Neck, 1/4" Carbon Steel, 5 Wing Nut
- Rear Hose Hangers, 12"
- Three (3) 5" Steel Sight Eyes
- LED Work Light Kit
- Standard Tail Light Kit
- Discharge: 4" Nipple w/ Brass Lever Valve & Aluminum Camlock Fittings
- Inlet: 3" Nipple w/ Brass Lever Valve & Aluminum Camlock Fittings
- 4.5" Standard Vacuum/Pressure Gauge
- 1.5" Brass Vacuum & Pressure Relief Valves
- Chassis Mounting Kit
- Bright White Urethane Paint
- (additional color options available)
- Vacuum Pump System (mounted & tested)
- Full-Open Rear Door with Hydraulic Hoist & Door-Lift System
- Sight Tube or Load Level Indicator (mechanical or electronic)
- 25" & 36" Manways
- Stainless Steel Heated Valve Collars
- Front Load Valve
- Hot-Dip Galvanizing
- Rhino Lining
- Aluminum Tank & Hose Tray Protection
- Internal Epoxy Coating
- Custom Paint Design
- Custom Vinyl Decals (Logo, Contact Info & Complimentary Art)
- 1/4" Carbon Steel Construction
- 12” Primary Shutoff
- 10 Gal. Secondary Shutoff
- Top (20") & Rear (20”) Manways
- Access Ladder (Curb-Side)
- Inlet (3") & Discharge (4") Ports w/ Lever Valves
- Work & Tail Lights Kits
- (3) 5" Steel Sight Eyes
- Full-Length Rails & Hose Trays
- Hose Hangers - 12"
- Vacuum Pressure Gauge
- Relief Valves
- Mounting Kit
- Bright White Paint
