Pister - Model BK3 -3-Way Diverter Ball Valve
The sealing function of BK3 and SK3 valves is only given when the pressure standing on the closed port is zero or if the pressure between the connected ports is higher than the pressure on the closed port. No shut -off position for third port is possible! To apply pressure from all ports, a special variant is required. Add A to the order code.
Most popular related searches
Material:
- Steel
Connector:
- compression fitting light and heavy series, BSP thread, NPT thread, UNC/UNF female thread, bulkhead connection, Thread connection
Description
- Dimensions: DN04 to DN25
- Body: S460N
- Ball + stem: free cutting steel, stainless steel (1.4571/316Ti)
- Sealing: plastics, metal
- Pressure range: up to PN400 (note table of dimensions)
- Field of application: hydraulics, particularly in construction industry and agricultural machinery, mining industry (Material of seals and body adapted to application!)
- Temperature range: standard:-20°C to +80°C (-4 to +176°F)
- Surface: black oxide finishing, zinc-layer, zinc nickel
