Lev-Co - Model DT3000V2 -05-005 -3.5`D X 5.5`W or 3.5`D X 8`W Self-Contained Downdraft Table

Draws contaminants away from workers’ breathing zone without hindering movement.

It uses (6) CLEAN-2 ULTRA high-efficiency cartridge filters (150 SQ. FT. each / 900 SQ. FT. total)

The VIBRA-PULSE filter cleaning system allows the filters to be cleaned on the spot.

Available with:

• Filter Options
• Localized Enclosures and Shields
• Silencer Option
• VFD Options
• Fan/Motor Upgrades or Options

• 10, 12 & 14 gauge welded steel cabinet with a powder-coat finish.
• The table includes two access covers for filter removal.
• Removable panel for access to Class II, backward incline, non-sparking blower and motor wired to an external junction box. (Motor starter not included.)
• Available in 2 standard sizes: 42``D X 66’’W or 42`` X 96

• Integral collection area and work surface:Draws contaminants away from workers` breathing zone without hindering movement; large work area meets a range of applications.
• Direct-Drive FRP Blower:Higher static pressure, longer filter life and greater reliability; spark resistant; no belts or pulleys to replace.
• Non-electrostatic Operation:High reliability, low maintenance.
• Vibra-Pulse® Filter Cleaning System:Cleans filters 75% more effectively than reverse pulse systems.
• Compressed filter mounting:Eliminates contaminant bypass of filters.

Top 5 contaminants/processes/applications:

• Welding Fumes
• Composite Dust
• Dusts and Smoke from MRO operations
• Grinding Particles
• Paint Fumes

Don`t see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.

Down Draft-Back Draft-9x4
9x4ft down & back draft table. Heavy duty. 4000lb weight capacity. Can handle flame, carbon arc, high psi. 14inch diameter duct connections.

DT3000-v2.0
3000 cfm heavy duty downdraft table, 42 deep x 66 wide work surface at 33 height, 200 fpm downdraft velocity, with baffled inlet spark trap. Contains (6) CLEAN-2 ® cartridge filters (150 sq.ft. of media), manual VIBRA-PULSE ® filter cleaning system and a 3 HP TEFC motor 230-460/3/60 Hz. AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

DT3000V2-48x96
3750 cfm heavy duty downdraft table, 48 deep x 96 wide work surface at 33 height, 150-200 fpm downdraft velocity, with baffled inlet spark trap. Contains (6) CLEAN-2 ® cartridge filters (150 sq.ft. of media), manual VIBRA-PULSE ® filter cleaning system and a 5 HP TEFC motor 230-460/575/3/60 Hz. AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.

• Filter Options (when ordering with main unit)
• Replacement Filters
• Localized Enclosures and Shields
• Sound Attenuation
• Variable Frequency Drives
• Accessories
