Sumoto - Model OP4 Series -4 Inch Rewindable Oil Filled Submersible Motor

Rewindable. Upper bracket: Nickel plated cast iron. SS304 cover sheet / Brass / SS316 available. Motor case: SS 304. Motor shaft: SS 304. Shaft extention and coupling: NEMA Standard. High quality radial and thrust ball bearings. Winding: enameled copper – Class F insulation. Degree of protection IP68/Class B insulation . Max temp. 35° with water cooling flow min. 0.08 m/s. Max depht immersion: 150 m. Nos. of start per hour: max 30 at regular intervals. Over-dimensioned sand slinger. Mechanical seal: graphite/ceramic. SiC/SiC or SiC/Al mechanical seal available as option. Coolant: dielectric non toxic high quality lubricant. Motor cable length: 1,75 to 4 m according to motor size (3 wires plus ground). Voltage variation: +/-10%. Single phase motor available in both.
