Numatics - Model 503 -4 Way Directional Control Valve
FromASCO Valve, Inc.
Numatics 503 Valve series provides higher flow and higher reliability in one versatile valve platform. Our 503 Series is available in dual 3-Way and 4-Way solenoid air pilot actuated valves. 503 Series valves are available with manifold or individual base mountings, proprietary or ISO 15407. Numatics 503 series valves are compatible with the Numatics G3 Fieldbus Electronics Platform.
Most popular related searches
directional control valve
actuated valve
pneumatic valve
package water
control valve
industrial water
pilot solenoid valve
air valve
valve actuator
gaskets
- G3 Electronics Compatible
- Solenoid air pilot actuated
- Low wattage, 1.7 watt for DC application
- DC solenoids polarity insensitive with surg suppression
- Plug together circuit boards eliminate internal wiring
- Integral recessed gaskets
- Push-in Fittings to accommodate various tubing sizes
- Simple conversion from internal to external pilot
- IP 65 Certified
- Cv 1.0 – 1.4
- Port Sizes: ¼, 3/8, 8mm, 10mm, Push-In, NPTF & G Tap
- 5 ported, 2X3-Way, 2 and 3 position, 4 Way, spool & sleeve & rubber seal
- Operating Pressure Range: 28" HG. Vacuum to 115 PSIG/ Vacuum to 8 Bar
- Pilot Pressure Range 29 to 115 PSIG / 2 to 8 Bar
- Temperature Range(Ambient): -14 °F to +115 °F/ - 10°C to 50 °C
