Jonloo - Model 150 LB -6 Inch Wafer Type Spring Loaded Dual Plate Check Valve

SHARE

China Check Valve Factory JONLOO supplies Dual Plate Check Valve, also called dual check valve. The valve is available in wafer type, lug type and flange type. Pls contact JONLOO if you need.

Most popular related searches
wafer dual plate check valve
check valve
ASTM a216
ASTM A105
spring check valve

Details

  • Size: 6 Inch.
  • Pressure: 150 LB.
  • Body: ASTM A216 WCB.
  • Disc: Stainless Steel
  • Seat: ASTM A105+13CR.

Standards

  1. Design&Mamufacture: API 594, API 6D
  2. Face-to-face API 594, API 6D, DIN 3202
  3. Flange end: DIN2543-2548, API605, ASME B 16.47, ANSI B 16.5
  4. Inspection and test: API 598
  5. Special: NACE MR-01-75
  1. Tightened Pin structure.
  2. Wafer end & Dual Plate design.
  3. Dual Plate With Spring Loaded structure
  4. Application: Chemical processing, Oil Field & Power Plant, Hydrocarbon processing
