Nano - Model N50SS 0060 (Grade) -60 SCFM High Pressure Stainless Steel Filter
Manufactured from high grade stainless steel, nano F4 high pressure stainless steel filters are designed to exceed requirements for many high pressure applications including PET, offshore and instrumentation.
Most popular related searches
differential pressure indicator
compressed air filtration
ASME pressure vessel
pressure filter
hydrostatic test
condensate draining
glass microfiber
borosilicate glass
hydrostatic testing
drain plug
- rated flow (scfm) (1): 60
- operating limits
- design operating pressure range (psig) (2): 0 to 725
- design operating temperature range (°F): 35 to 248
- housing construction
- materials 316: stainless steel
- element construction
- media: borosilicate glass microfiber
- end caps: glass filled nylon
- replacement element (part no): E50SS 0060 (grade)
- components
- condensate drain: manual ball valve as standard
- differential pressure indicator / gauge: -
- air circuit
- inlet & outlet connections (NPT): ¼”
- A (ins): 3.35
- B (ins): 0.71
- C (ins): 6.69
- D (ins): 2.95
- weight: (lbs) 3.7
- designed in accordance with ASME pressure vessel standards
- manufactured in an ISO 9001 approved facility and tested in accordance with ISO 8573.1:2010
- push fit element design eliminates risk of contaminant bypass
- hydrostatic tested prior to despatch to guarantee quality and performance
- threaded filters are PED 2014/68/EU compliant for group 2 gases
- supplied with drain plug. High pressure drains available as option
