Mid Wave - Model IRC806HS -640×512 Indium Antimonide (InSb) MWIR Infrared Camera

SHARE

Utilizing a high speed MWIR focal plane array the IRC806HS provides superior performance in a large format infrared imaging camera.  Operating at up to 478 frames per second full frame, this 20 micron camera supports sub-windowing for even higher frame rates.  Super framing allows the camera to switch among different integration times on a frame by frame basis to image rapidly changing scenes over a wide dynamic range.  Full rate image data is available via Camera Link, and simultaneous Gigabit Ethernet.

Most popular related searches
infrared camera
optical filter
  • Detector:
    • Detector type: Indium Antimonide (InSb)
    • Spectral response:
    • Resolution (pixels): 640 x 512
    • Pixel pitch: 12µm
  • Imaging Electronics:
    • Frame rate @ max window size: 475 Hz
    • Integration time:
    • Dynamic range: 14-bits with 13-bit option to increase frame rate at small window sizes
    • Windowing: User defined in 4×1 increments; min width=320, min height=32
    • Integration type: Snapshot, automatic selection of integrate while read or integrate then read
    • Ultra low latency sync: Sync I/O, integration out
    • Image data: Simultaneous Camera Link & Gig-E
    • Communications: Serial over Camera Link & Gig-E
    • Software control: Cross platform GenICam compliant
  • Performance:
    • NEdT: < 30mK
    • Well capacity (electrons): 2M
    • Operability: 99.6%
    • LN2 hold time: > 8 hours typical, >4 hours with optional cold filter wheel
  • Optics:
    • Camera f/#: f/2.3, f/3.0 & f/4.0 standard; custom cold shields available on request
    • Cold filter: 3.0µm – 5.0µm or no cold filter standard, optional CO2, SWIR or custom filters on request
    • Lens mount: Bayonet for 7, 13, 25, 50, 100 & 50/250 mm lenses; bolt hole pattern for non-standard lenses
    • Optional filter wheel: Motorized four position cold filter wheel; 25.4mm diameter x 1.0mm thick filters
  • General:
    • Power @ 24 VDC: 12 watts
    • System weight: < 7 pounds
    • Size: 3.7″ x 8.1″ x 11.8″
    • Operating temperature range: -40C to +55C (-40°F to +131°F)
    • Storage temperature range: -55C to +80C (-67°F to +176°F)
    • Environmental rating: IP-51
    • Mounting holes: 2x 1/4-20 & 4x #10-24
