Lotus Pipes & Rockdrills USA Ltd.
Lotus - Model FDD 38 -8 Inch DTH Hammer
8” DTH Hammer, with Top connection Threads 4 1/2” API REG PIN, Shank Type – DHD 380 Hammer. SUITABLE BUTTON BITS : Flat face(Optional – Concave Face). Dia – 8” ( 203 mm)*, Dia – 8 ½” ( 216 mm). Dia – 9” ( 229 mm)*, Dia – 10” ( 254 mm). Dia – 10 ½” ( 280 mm).
Most popular related searches
- Hammer to Drill a hole of dia 200-254 mm (7 7/8”– 10”).
- Lotus _FDD38 is a valve less type hammer designed for high performance at low operating air pressures
- DHD380 bit has a strong robust design to withstand heavy duty application and it does not use foot valves which reduces the possibility of hammer failure
- Lotus _FDD38 Hammer maximizes energy output and reduces service requirements.
- Wear sleeve is reversible.
- Single Start threads on Top sub and Drive sub ensure easy coupling/uncoupling of hammer.
- All critical internal components are heat treated under strict control to maximize tool longevity.
- An overall cost-effective and user friendly tool for use in the most demanding conditions.
