Abracon ClearClock - Model AX5DBF1-156.2539C -Oscillators
FromAbracon
Frequency 156.253906 MHz. Subtype Crystal. Operating Temperature -40°C ~ 85°C. Frequency Stability ±20ppm. Package / Case 8-SMD, No Lead. Part Status Active. Length 5. Type XO (Standard). Width 3.2. Mounting Type Surface Mount. Series ClearClock™ AX5. Height 1.5. Voltage - Supply 2.5V. Output LVDS. Function Enable/Disable. Current - Supply (Max) 80mA. RMS Phase Jitter (TYP) 150fs. Brand Abracon.
- Ultra-Low Jitter: 125 fs Typ RMS (200fs MAX, F>250MHz); spurs included
- Available with any frequency from 50MHz to 2100MHz
- Factory programmable; samples available within 1-2 week lead times
- Lowest in-class power consumption (60mA Typ LVDS)
- ±20ppm stability (-40 to +85ºC)
- 3.3V, 2.5V, 1.8V Vdd supply
- LVPECL, LVDS, HCSL, & CML differential output options
- Industry standard 5.0 x 3.2mm footprint
