Salem-Republic - Acid Resistant / Chemical Transfer Hose

Tube and cover polymers include pure gum rubber, styrene-butadiene rubber (SBR), Hypalon®, neoprene, nitrile, butyl, EPDM, Viton® and polyethylene.

Any of our custom built hose can be manufactured with color-coded exterior. Color ID applications include modifying the cover or incorporating stripes to meet your particular plant production identification requirements.

Cross-Linked Polyethylene Acid / Chemical Transfer Hose

S-R Hand-Wrapped Cross-Linked Polyethylene hose is the most versatile of medium priced hose. It is capable of handling over 90% of industrial chemicals with the exception of strong oxidizing acids. A high tensile wire helix makes a rugged and highly flexible hose outstanding for both suction and discharge service. The clear, largely inert cross-linked polyethylene tube will not interact with most chemical products, thereby avoiding product contamination. Hence, the XLPE tube eliminates need and extra expense of specialized hoses for processing, loading, and storage service. Use S-R’s XLPE hose for service to 140°F. Its green Hypalon® cover with bright yellow stripe easily identifies this hose.

Abrasion & Ozone Resistant

The Hypalon® cover protects the body from the stiffening and cracking caused by ozone and UV. It also adds abrasion resistance for extended hose life.

Non-Kinking

S-R’s unique handmade hose features high tensile helix wire for strongest construction, which permits shortest bend radii while assuring full vacuum service without kinking.

Multi-Ply Acid Discharge Hose

Designed to handle most of the common acids and alkali solutions under pressure. S-R’s acid discharge hose features softwall construction available with tube and cover compounds shown above. Standard gauges are 1/8″, 3/16″ and 1/4″.

Multi-Ply Acid Suction Hose

This hose features a high-tensile spring steel wire helix to prevent collapse under vacuum. Smooth seamless 3/16″ or 1/4″ tube thickness is standard with heavier gauges available upon request.

Other Uses

• Custom Lengths
• Custom Tube Linings
• Custom Wall Thickness
• Reinforcement Options
• Custom Cover
