ADES - Mixed Polygeneration Systems
The polygeneration seeks to obtain a continuous supply of electrical energy depending on the energy sources availability and maximum fuel economy. An intelligent system prioritizes most suitable energy source at all times.
Most popular related searches
Mixed Polygeneration Systems:
- Synchronous generator : 250 kW
- Thermal engine * : 250 kW (Diesel or Gas)
- Wind support system : 170 kW (saving in fuel)
- Photovoltaic field : 200kW (with E-W tracking +/- 40º)
Maximum Available Electrical Power
- Only thermal engine : 250 kW
- Thermal + wind : 250 kW (saving in fuel)
- Thermal + solar : 450 kW
- Thermal + wind + solar : 450 kW (saving in fuel)
Mixed Polygeneration Systems
Direct fuel saving into the thermal engine. The equipment consists of a wind turbine of 32 m rotor diameter, which at nominal speed of 10.5 m / s, provides mechanically 170 kW to the generator rotations providing torque on shaft by means of a hydraulic servo motor.
It provides electricity directly unloading the synchronous generator, reducing fuel consumption or increasing available electricity.
