Voyager - Adjustable Tip Spacing Pipette
In the past, scientists were restricted to use single channel pipettes when transferring samples between labware of different formats. Such single transfers as gel loading, tube to plate transfers or 96-well to 384-well plate reformatting are tedious and an error prone tasks. VOYAGER multichannel pipettes have been designed to address this problem specifically. It is the first and only automatic adjustable tip spacing pipette on the market. Using a VOYAGER you can transfer multiple samples at once in the blink of an eye. Moreover, by reducing transfer steps, VOYAGER helps you prevent repetitive strain injuries (RSI) and pipetting errors.
VOYAGER pipettes feature a unique motorized tip spacing, enabling parallel transfer of multiple samples between labware of different sizes and formats. The tip spacing can be changed by a simple push of a button.
-
Electronically Adjustable Tip Spacing
VOYAGER pipettes allow the tip spacing to expand anywhere between 4.5 mm and 33 mm at the push of a button.
The motorized tip spacing offers many advantages over manual tip spacing adjustments:
- Single handed operation leaves the other hand free to handle labware.
- On the fly access to up to 3 user-defined tip spacings.
- These user defined tip spacings are saved. No need to memorize spacings of different labware formats.
For more information about VOYAGER tip spacing and compatible labware, please download VOYAGER APPLICATION GUIDE.
-
GripTip pipette tips which never leak or fall off
GripTips are always firmly attached and perfectly aligned, regardless of how many side well touch offs are performed. You no longer have to hammer your pipette tips on or worry about pipette tips falling off!
1) LOBES
2) O-RING Seal
3) RIM SNAPS OVER THE LOBES
4) SHOULDERThe rim (3) of the GripTips will snap over the Multi-Lobes (1), attaching firmly. As a result, GripTips will never accidently fall off.
A shoulder (4) provides a positive stop to prevent over-tightening of the tip. It can only be attached up to that point and no further, ensuring that all tips are at the same height. As a result, the tip is either on or off, but nothing in between.
-
Intuitive operation and navigation
The Touch Wheel interface offers a quick and ergonomic way to modify pipetting parameters. It enables you to browse through menus, change pipetting volumes and speeds or other settings. Changing a dispense volume has never been so fast and easy!
The full color screen provides full text menus and displays pipetting protocols without abbreviations, making INTEGRA`s pipettes particularly easy to understand and intuitive to use.
-
Various pipetting modes
For the most common liquid handling tasks 10 preset pipetting programs are available, in which only basic parameters need to be defined.
For more elaborate pipetting protocols, up to 40 user defined custom programs can be created.
1) Currently active pipetting mode
2) Next pipetting step is marked
3) Aspiration volume
4) Other parameters such as speedIf connected to the VIALINK PIPETTE MANAGEMENT SOFTWARE, even complex custom programs can be quickly created and stored in a library on the computer.
