ADS Biotec - Model QuickGene Auto24S -Nucleic Acid Extraction System
The QuickGene Auto24S Nucleic Acid Extraction System is a compact, automated system designed to efficiently isolate DNA and RNA from multiple sample types. Like the QuickGene 240L system, its patented technology uses a unique porous membrane for high quality throughout yields. A full range of DNA extraction kits and RNA extraction kits is also available.
The QuickGene Auto24S is a fully automated system for rapid Nucleic Acid Extraction and Purification of DNA & RNA from various sample types, including whole blood, tissue, cells, plants, and viruses. The compact unit can process 24 samples, up to 200 µL, in a single run, making efficient use of laboratory bench space.
With its ultra-thin polymer membrane, the QuickGene technology allows for effective capture of nucleic acids. This novel low-pressure design requires no centrifugation, delivering quality DNA with high-purity yields.
QuickGene Nucleic Acid Extraction Systems are made in Japan.
Automated DNA RNA extraction
Fully automated DNA/RNA extraction process from primary tube to final storage tubes. The system uses pre-filled, single-use cartridges that can run independently, providing added flexibility and, most important, avoiding any risk of contamination or human error processing. Convenient benchtop design is easy to use, low maintenance, and helps increase lab productivity. Performs consistent, reliable DNA isolation of 24 samples, 200 µL each, within 30-80 minutes.
Patented porous membrane for high-yield, high-purity isolation
The nucleic acid adsorptive medium used in the QuickGene Auto24S system is a porous membrane developed through application of advanced polymer membrane production technology. It is only 80 μm thick, making it incomparably thinner than conventional glass fibers. Because of the outstanding adsorptive and desorptive performances of the membrane, nucleic acid can be rapidly and reliably isolated at low pressure without being damaged, which realizes high-quality nucleic acid isolation
UV irradiation
Built-in UV Lamp enables decontamination and minimizes the sample cross-contamination
- Throughput : 1 to 24 samples per run
- Elution volume : 50, 100, 150, 200 μl
- Sample volume : 200 μl
- Processing time : 30 – 80 minutes
- depends on protocol
- Power supply : AC100-240V, 50/60Hz
- Dimensions : W740 x D630 x H620 mm
- Weight : 75 kg
