Adsensors - Model 980MPT -Dual Channel pH/TDS Indicator/Controller/Transmitter

SHARE

These instruments are menu driven. Auto calibration and standard self diagnostic features are incorporated. 2 Line 16 character alpha numeric backlit LCD for display. Channel 1 for pH and channel 2 for TDS. Range for each channel can be selected by menu. Two parameters will be simultaneously displayed. Independent current output for both channels (isolated 4-20 mA). Alarm can be configured. Ideal for RO plant application.

Most popular related searches
pH/conductivity/TDS
pH/ORP/conductivity
conductivity/TDS
TDS
TDS range
reverse osmosis plant
calibration standard
TDS control
TDS controller
pH indicator

980MP/980MC/980MT/980MO/980MN are microcontroller based Instruments These Instruments are panel mountable. The dimensions are 96x96x150mm. These Instruments are available in single channel/two channel version. The channel selection is available among the following parameters Viz pH / Conductivity / TDS / ORP. These Instruments can be offered as

  • Indicators only
  • Indicators and controllers
  • Indicators with standard 4-20 mA current output. The current output is isolated

It is to be noted that a total of three control outputs and two currents outputs are available in multichannel Instruments. The choice of control output for the parameter is possible. The current output can be configured to any parameter of interest.

Temperature compensation is provided in the software for pH and Conductivity. For conductivity, the temperature coefficient selection for different medium under measurement is possible in steps of 0.1% upto 3%.

These instruments are available in single channel and Dual channel versions Possible combinations of dual channel versions are

  • pH/ORP
  • pH/Conductivity
  • pH/TDS
  • Conductivity/Conductivity
  • TDS/TDS
  • Conductivity/TDS

  • The instrument is based on ATmel micro controller with 12 bit ADC
  • Two line ,16 Character (16X2) AlphaNumeric LCD Display
  • Three alarm outputs are provided. The alarm setting is programmable.
  • 230V/110V AC 50Hz Supply
  • RS 485 with PC interface and Software(optional)
  • The Instruments are panel mountable DIN Size enclosure.
  • Auto Zero and span adjustment
  • Self diagnostic feature
