AFT - Portable Ultrasonic Flow Meter
Ultrasonic flow meter is designed to work with clamp-on transducers to enable the flow of a liquid within a closed pipe to be measured accurately without needing to insert any mechanical parts through the pipe wall or protrude into the flow system. Using ultrasonic transit time techniques the is controlled by a micro-processor system which contains a wide range of data that enables it to be used with pipes with an outside diameter ranging from 15mm up to 6000mm (depending on model) and constructed of almost any material. The instrument will also operate over a wide range of fluid temperatures.
High Accuracy
Accuracy better than 1%.
Measure Range
Select different model sensorscan achieve DN15-DN6000mm pipe flow measurement
High Reliability
Adopt low voltagemulti-pulse radiating circuit.AccuracyLifetime and Reliability are better.
High Anti-interference
Adopt double balanced signal differencial transmissionreceiving circuit
effective resist the drivetower Strong power lines and other source of interference.
Powerful Memory Function
- Automatic memory the cumulative flow of 512 days before 128 months before 10 years before.
- Automatic memory the power-on and off of 64times before and the flow.
- Automatic memory the meter working condition of 32days before.
Support Temperature Sensor
Connect with Temperature sensorit can measure heat flow.
Support SD card memory
Select SD card memoryit can realize mass storage by ultrasonic flowmeter
