Coantec - Model BLX Series -AI Powered Industrial Videoscope with 3D Measurement and NPU Computing

Ergonomic controls include voice commands and a responsive joystick for effortless operation. Built to withstand harsh conditions, this industrial endoscope offers IP65 protection for the host, IP68 for the insertion tube, and optional cold-resistant mode down to -40°C, ensuring reliable performance in aerospace, automotive, and energy applications.

• Tube diameter: 0.95 / 1.2 / 1.6 / 1.8 / 2.0 / 2.8 / 3.0 / 3.9 / 4.8 / 6.0 / 8.0
• Camera pixels: 500w
• Tube length: 1m~10m

The BLX series Al-Powered Industrial Videoscope, developed by Coantec, is powered by a dedicated NPU neural network processor that delivers a 12-fold increase in computing power, enabling zero-delay Al image processing and precise voice interaction. Its 5.5-inch industrial touchscreen integrates with a modular insertion tube system for rapid adaptation to various inspection scenarios, while ensuring long battery life, low-temperature resistance, and superior protection.

Smart 3D Measurement
Real-time acquisition of high-density point cloud data generates clear 3D point cloud maps, supporting precise defect detection and analysis.

Multi-Dimensional Accurate Calculation
Capable of measuring point-to-point, point-to-line, point-to-plane, multi-segment, area, profile, missing corner, circle, gap, etc. Data is stable and reliable, meeting the demands of complex scenarios.

AI Algorithms
Integrates high-performance image processing and AI technology to adapt to complex environments, ensuring imaging quality and measurement accuracy.

AI Intelligent Interaction and Preception

AI Intelligent Defect Recognition
Equipped with an NPU computing chip, achieving full digital intelligent detection. Not only has the ability to qualitatively judge defects, but also can perform rapid quantitative analysis and automatically identify defect types.

Voice Interaction System
A new voice interaction system, configured with ConaTec’s ecosystem AI intelligent voice intercom system, supports voice command control.

Noise Reduction Recognition
Noise reduction recognition rate exceeds 95% in noisy environments, doubling inspection efficiency.

Environmental Awareness Sensors
Built-in temperature and ambient light sensors enable intelligent linkage, making the device more “context-aware”:

Automatically initiates preheating in low-temperature environments reduces startup time adjusts brightness automatically for low-light conditions

All-in-One Power Solution
Fast-charging technology (80% charge in just 30 minutes) detachable battery design

Supports high-intensity operation for up to 4 hours (approx. 3 hours in low-temperature environments)

Multiple battery modules available for all-weather inspection

Battery status can be monitored anytime, even when powered off operating with a single battery. making usage more convenient and efficient

Revolutionary Imaging System

High-Resolution Ultra-Clear Imaging
Equipped with 7 types of professional light sources (single white/single UV/single infrared/UV-white/UV-infrared/infrared-white/laser, etc.), greatly improving color reproduction and detail rendition.

Intelligent Noise Reduction Algorithm
Supports 120Hz high frame rate full-pixel video recording, paired with intelligent noise reduction, ensuring smooth images without ghosting and clearly visible minor defects.

High-Brightness Auxiliary Lighting System
Uses independent dimming technology for each circuit, enabling synchronous full-light observation. Brightness is improved by 3 times compared to traditional lighting, allowing thorough inspection in corners and detection of hidden defects.

Modular Flexible Configuration / Ergonomic Design

Modular Flexible Configuration
Supports interchangeable insertion tubes and lenses of different specifications. Compatible with ConaTec’s 5th generation optoelectronic lenses and Xiangyun lens case (including direct view, side view, far focus, near focus, macro, and various other lenses), enabling free switching and covering all scenarios with one device.

Ergonomic and Portable Design
Features an integrated handheld body structure, lightweight and easy to grip, comparable to portable products. Can be comfortably operated with one hand, allowing flexible maneuvering in tight spaces and enabling inspections on the go.

Precise and Effortless Control
Electric joystick + 5-way navigation button enables 360° all-directional control with a 50% improvement in response speed
Anti-slip base supports both flat placement and upright positioning Ensures stable multi-mode operation for precise and effortless control

Widely Applied:

Aerospace:
Internal defect detection for engine blades, combustion chambers, turbine structures, fuel nozzles, etc.

Automotive Manufacturing:
Inspection of engine block, valves, and internal cleanliness and assembly status of transmission.

Energy and Power:
Internal inspection of boiler pipelines, heat exchangers, transformer oil tanks, and wind turbine gearboxes.

Petrochemical: (corrected from “Etrochemical”)
Pipeline and tank inspection at refineries, reactor and heat exchanger inspection at chemical plants, maintenance of oil and gas transmission pipelines.

Rail Transit:
Evaluation of internal conditions of bogie hollow shafts, brake system piping, and air conditioning ducts.

Construction Engineering:
Detection of internal cavities, clogged drainage pipes, and dust accumulation in ventilation systems for concrete structures.

Special Equipment:
Regular inspection and safety assessment of pressure vessels, boilers, and pressure pipelines.

Military Industry and Research:
Internal inspection of weapon components, material structure observation, and teaching experimental demonstrations.
