Ecomesure - Model CAVOK UAS CK 9 -Air Quality Monitoring Drone
Ecomesure offers an on-board environmental monitoring solution that consists of its EcomTrek portable monitoring station mounted on a CAVOK UAS CK 9 drone.
This integrated solution measures concentrations of multiple pollutants in hard-to-reach, hazardous or specific areas of interest — such as smoke plumes and gas leaks — all in real time.
When mounted on the CK 9, EcomTrek takes your measurements to a higher level by mapping air quality across vast distances at various altitudes.
All the data collected during each measurement survey are sent in real time to Ecomesure`s ws.i-comesure web platform for simplified data visualization, management and analysis.
The CK 9 is made in France and is particularly recommended for flights over sensitive sites.
- Easy to transport and deploy
- Rugged and silent
- Centimeter accuracy and flight stability
- Industrial production facilities
- Gas and oil pipelines
- Waste management facilities
- Industrial accidents
- Dimensions Mounted : 390 x 740 x 740 mm (15.4 x 29.1 x 29.1 inches)
- Folded : 130 x 355 x 355 mm (5.1 x 14 x 14 inches)
- Weight 4.5 kg (9.9 lbs) including battery (7S 16 Ah Li-Ion Solid State)
- Maximum takeoff weight 9 kg (19.8 lbs)
- Maximum payload 4.5 kg (9.9 lbs)
- Maximum speed 23m/s (0.0143 miles/s)
- Maximum altitude 3 500 m (2.174 miles)
- Endurance 1 hour without payload
- Control and communication Transmission frequency for telemetry and video: 5.8 GHz.
- Radio control range: 3 to 5 km, integrated screen with Android operating system.
