All-Flo - Model 1/2-A050 -Plastic Diaphragm Pumps

SHARE
Air Inlet: 1/4" FNPT.  Liquid Inlet: 1/2".  Liquid Discharge: 1/2".  Connection Type: FNPT/FBSPT (Threaded).  Max Suction Lift Capability: 15 ft-H2O (4.6 m-H2O) Dry, 26 ft-H2O (7.9 m-H2O) Wet.
Most popular related searches
diaphragm pump
air intake
diaphragm air pump
air diaphragm pump
muffler
air pump
Max Flow Rate
  • 17 gpm (64.6 lpm)
Max Pressure
  • 120 psi (8.2 bar)
Max Diameter Solids
  • 1/8" (3.2 mm)
Displacement Per Stroke
  • 0.03 gal (0.10 L)
  • Max Flow: 17 gpm (64.6 lpm)
  • Max Air Pressure: 120 psi (8.2 bar)
  • Max Static Suction Head: 23 ft-H2O (7.0 m-H2O)
  • Max Static Suction Lift (Dry): 15 ft-H2O (4.6 m-H2O)
  • Max Suction Lift (Wet): 26 ft-H2O (7.9 m-H2O)
  • Max Solids: 1/8 in. (3.2 mm)
  • Avg. Displacement Per Stroke: (0.03 gal / 0.10 L)
  • Sound Level: 83 dBA (with muffler)
