All-Flo - Model 1/4-A025 -Plastic Diaphragm Pumps

FromAll-Flo, A PSG BRAND

SHARE

Air Inlet: 1/4" FNPT. Liquid Inlet: 1/4".

Most popular related searches

diaphragm air pump

air diaphragm pump

Liquid Discharge

1/4"

Connection Type

FNPT/FBSPT (Threaded)

Max Suction Lift Capability

14 ft-H₂O (4.2 m-H₂O) Dry
28 ft-H₂O (8.5 m-H₂O) Wet

Max Flow Rate

5.7 gpm (21.6 lpm)

Max Pressure

120 psi (8.2 bar)

Max Diameter Solids

1/16" (1.6 mm)

Displacement Per Stroke

0.01 gal (0.04 L)

Max Flow: 5.7 gpm (21.6 lpm)
Max Air Pressure: 120 psi (8.2 bar)
Max Static Suction Head: 23 ft-H2O (7.0 m-H2O)
Max Suction Lift (Dry): 14 ft-H2O (4.2 m-H2O)
Max Suction Lift (Wet): 28 ft-H2O (8.5 m-H2O)
Max Solids: 1/16 in. (1.6 mm)
Avg. Displacement Per Stroke: (0.01 gal / 0.04 L)
Sound Level: 80 dBA (with Muffler)
