All-Flo - Model 1 -A100 -Plastic Diaphragm Pumps
Air Inlet: 1/4" FNPT. Liquid Inlet: 1". Liquid Discharge:1". Connection Type: FNPT/FBSPT (Threaded). ANSI/DIN (Flanged). Max Suction Lift Capability: 15 ft-H2O (4.6 m-H2O) Dry, 26 ft-H2O (7.9 m-H2O) Wet.
Most popular related searches
Max Flow Rate
- 41 gpm (155.8 lpm)
- 120 psi (8.2 bar)
- 1/4" (6.4 mm)
- 0.08 gal (0.31 L)
- Max Flow: 41 gpm (155.8 lpm)
- Max Air Pressure: 120 psi (8.2 bar)
- Max Static Suction Head: 23 ft-H2O (7.0 m-H2O)
- Max Suction Lift (Dry): 15 ft-H2O (4.5 m-H2O)
- Max Suction Lift (Wet): 26 ft-H2O (7.9 m-H2O)
- Max Solids: 1/4 in. (6.4 mm)
- Avg. Displacement Per Stroke: (0.08 gal / 0.31 L)
- Sound Level: 80 dBA (with Muffler)
